el-col:如何让超过 24 格的元素一行显示
问题:
您希望让 element-ui 组件中的 el-col 元素在超过 24 格时依然保持在一行显示,并可以通过滚动条查看内容。
解决方法:
由于 el-ui 本身无法实现超过 24 格的一行显示功能,因此需要通过自定义实现。
您可以通过以下步骤自定义实现该功能:
<template>
<div>
<div ref="container">
<slot v-bind="$attrs" />
</div>
<div ref="scrollbar" style="width: 100%; height: 16px; overflow-x: scroll;">
<div ref="scrolltrack" style="width: 100%; background: #ccc;"></div>
<div ref="scrollbarhandle" style="width: 24px; height: 16px; background: #666; border-radius: 8px; position: absolute; left: 0;"></div>
</div>
</div>
</template>
<script>
import { ref } from '@vue/reactivity';
import { onmounted, onunmounted } from '@vue/runtime-core';
export default {
setup() {
const container = ref(null);
const scrolltrack = ref(null);
const scrollbarhandle = ref(null);
const scrollbar = ref(null);
let scrollleft = 0;
let handleleft = 0;
let handlewidth = 0;
function updatescrollbar() {
if (!container.value || !scrolltrack.value || !scrollbarhandle.value) return;
const containerwidth = container.value.clientwidth;
const scrolltrackwidth = scrolltrack.value.clientwidth;
handlewidth = (containerwidth * scrolltrackwidth) / scrollbar.value.scrollwidth;
handleleft = (scrollleft / scrollbar.value.scrollwidth) * scrolltrackwidth;
if (handlewidth < 24) {
handlewidth = 24;
}
scrollbarhandle.value.style.width = `${handlewidth}px`;
scrollbarhandle.value.style.left = `${handleleft}px`;
}
function onscroll() {
if (!container.value || !scrolltrack.value || !scrollbarhandle.value) return;
scrollleft = scrollbar.value.scrollleft;
updatescrollbar();
}
function onhandlemousedown(e) {
if (!container.value || !scrolltrack.value || !scrollbarhandle.value) return;
const scrollbarwidth = scrollbar.value.clientwidth;
const handlewidth = scrollbarhandle.value.clientwidth;
const scrollbarhandleminleft = 0;
const scrollbarhandlemaxleft = scrollbarwidth - handlewidth;
e.preventdefault();
e.stoppropagation();
document.addeventlistener('mousemove', onhandlemousemove);
document.addeventlistener('mouseup', onhandlemouseup);
const onhandlemousemove = (e) => {
const offset = e.clientx - container.value.offsetleft - handlewidth / 2;
if (offset < scrollbarhandleminleft) {
offset = scrollbarhandleminleft;
} else if (offset > scrollbarhandlemaxleft) {
offset = scrollbarhandlemaxleft;
}
const newscrollleft = (offset / scrollbarwidth) * scrollbar.value.scrollwidth;
scrollbar.value.scrollleft = newscrollleft;
e.preventdefault();
e.stoppropagation();
};
const onhandlemouseup = () => {
document.removeeventlistener('mousemove', onhandlemousemove);
document.removeeventlistener('mouseup', onhandlemouseup);
};
}
onmounted(() => {
scrollbar.value = scrollbar.value || container.value.parentelement;
updatescrollbar();
scrollbar.value.addeventlistener('scroll', onscroll);
scrollbarhandle.value.addeventlistener('mousedown', onhandlemousedown);
});
onunmounted(() => {
scrollbar.value.removeeventlistener('scroll', onscroll);
scrollbarhandle.value.removeeventlistener('mousedown', onhandlemousedown);
});
return {
container,
scrolltrack,
scrollbarhandle,
};
},
};
</script>
<style>
.container {
display: flex;
overflow: hidden;
width: 100%;
height: 100%;
}
.scroll-track {
position: relative;
flex-grow: 1;
}
.scrollbar-handle {
position: absolute;
z-index: 100;
cursor: pointer;
}
</style>在您的代码中,用自定义容器组件替换原有的 el-row 组件。
<template>
<div>
<MyContainer>
<el-col :span="8">
<div class="grid-content bg-purple"></div>
</el-col>
<el-col :span="8">
<div class="grid-content bg-purple-light"></div>
</el-col>
<!-- ... 其它内容 -->
</MyContainer>
</div>
</template>
<script>
import MyContainer from './MyContainer.vue';
export default {
components: { MyContainer }
};
</script>这样,超过 24 格的元素就会在一行显示,并可以通过滚动条滚动查看。
