在网页浏览器中绘制并标注三角形
本文介绍如何在浏览器中绘制三角形并标注其边长和角度。 有多种方法可实现此功能,各有优劣:
对于已知边长和角度的三角形,推荐使用 Canvas 或 SVG。 下面是一个使用 Canvas API 的示例:
// 创建画布元素 const canvas = document.createElement('canvas'); canvas.width = 400; canvas.height = 400; document.body.appendChild(canvas); const ctx = canvas.getContext('2d'); // 定义三角形顶点坐标 const A = { x: 50, y: 300 }; const B = { x: 250, y: 300 }; const C = { x: 150, y: 100 }; // 绘制三角形 ctx.beginPath(); ctx.moveTo(A.x, A.y); ctx.lineTo(B.x, B.y); ctx.lineTo(C.x, C.y); ctx.closePath(); ctx.stroke(); // 计算边长 function distance(p1, p2) { return Math.sqrt(Math.pow(p2.x - p1.x, 2) + Math.pow(p2.y - p1.y, 2)); } const AB = distance(A, B); const BC = distance(B, C); const CA = distance(C, A); // 计算角度(弧度转角度) function angle(p1, p2, p3) { const a = distance(p2, p3); const b = distance(p1, p3); const c = distance(p1, p2); return Math.acos((a * a + b * b - c * c) / (2 * a * b)) * 180 / Math.PI; } const angleA = angle(B, A, C); const angleB = angle(C, B, A); const angleC = angle(A, C, B); // 添加标注 ctx.font = '14px Arial'; ctx.fillText(`AB = ${AB.toFixed(2)}`, (A.x + B.x) / 2, (A.y + B.y) / 2 + 20); ctx.fillText(`BC = ${BC.toFixed(2)}`, (B.x + C.x) / 2, (B.y + C.y) / 2 + 20); ctx.fillText(`CA = ${CA.toFixed(2)}`, (C.x + A.x) / 2, (C.y + A.y) / 2 + 20); ctx.fillText(`∠A = ${angleA.toFixed(2)}°`, A.x - 20, A.y - 20); ctx.fillText(`∠B = ${angleB.toFixed(2)}°`, B.x, B.y - 20); ctx.fillText(`∠C = ${angleC.toFixed(2)}°`, C.x, C.y + 30);
这段代码会在页面上绘制一个三角形,并显示其边长和角度。 你可以根据需要修改顶点坐标来改变三角形的形状和大小。 记住需要将这段代码嵌入到<script>标签中,并确保你的HTML页面包含<canvas>元素。 或者,你可以创建一个新的HTML文件,将代码粘贴进去,然后在浏览器中打开该文件。</script>
