高并发环境下串口通信的高级抽象与实现

import queue
import threading
import time
import random

# 假设的串口操作函数
def _serial_write(data):
    print(f"[Serial] Sending: {data}")
    time.sleep(0.1) # 模拟写入延迟

def _serial_read(size):
    # 模拟读取响应
    response_map = {
        "foo": "temp_data",
        "bar": "config_ack"
    }
    # 假设响应与请求直接相关，实际可能需要解析设备返回
    # 这里简化为根据发送的数据模拟返回
    if "foo" in threading.current_thread().name: # 模拟foo请求的响应
        return response_map["foo"]
    elif "bar" in threading.current_thread().name: # 模拟bar请求的响应
        return response_map["bar"]
    return "unknown_response"

class SerialCommunicator:
    def __init__(self):
        self.request_queue = queue.Queue()
        self.response_queues = {} # 存储每个请求对应的响应队列
        self.serial_thread = threading.Thread(target=self._run_serial_handler, name="SerialHandlerThread")
        self.serial_thread.daemon = True
        self.serial_thread.start()

    def _run_serial_handler(self):
        while True:
            request_item = self.request_queue.get()
            query = request_item['query']
            response_queue = request_item['response_queue']

            try:
                # 严格的请求-响应周期
                _serial_write(query)
                response = _serial_read(8) # 假设读取8字节
                response_queue.put({"status": "success", "data": response})
            except Exception as e:
                response_queue.put({"status": "error", "message": str(e)})
            finally:
                self.request_queue.task_done()

    def send_query(self, query):
        # 每个请求创建一个临时的响应队列
        response_q = queue.Queue(1)
        self.request_queue.put({"query": query, "response_queue": response_q})
        # 阻塞等待响应
        result = response_q.get()
        if result['status'] == 'success':
            print(f"[{threading.current_thread().name}] Received response for '{query}': {result['data']}")
            return result['data']
        else:
            print(f"[{threading.current_thread().name}] Error for '{query}': {result['message']}")
            raise Exception(result['message'])

# 实例化串口通信抽象层
serial_device_abstraction = SerialCommunicator()

# 示例：线程1持续查询"foo"
def thread1_task():
    threading.current_thread().name = "Thread-Foo"
    while True:
        try:
            serial_device_abstraction.send_query("foo")
        except Exception as e:
            print(f"Thread-Foo encountered error: {e}")
        time.sleep(1)

# 示例：线程2随机查询"bar"
def thread2_task():
    threading.current_thread().name = "Thread-Bar"
    for _ in range(5): # 模拟查询5次
        time.sleep(random.uniform(0.1, 2.0))
        try:
            serial_device_abstraction.send_query("bar")
        except Exception as e:
            print(f"Thread-Bar encountered error: {e}")

# 启动线程
t1 = threading.Thread(target=thread1_task)
t2 = threading.Thread(target=thread2_task)

t1.start()
t2.start()

# 等待一段时间，观察输出
time.sleep(10)
print("Main thread exiting.")

// 假设 serial_fd 是串口的文件描述符
// 假设 serial_mutex 是一个全局或静态的互斥锁
// (在Python中，可以使用threading.Lock)

// C/C++ 伪代码示例
procedure serial_messaging(u8 *request_mesg, int rqlen, u8 *response_mesg, int rslen)
{
    int rc;

    acquire_the_mutex(serial_mutex);    /* 获取互斥锁，否则当前线程阻塞 */

    rc = write(serial_fd, request_mesg, rqlen);
    if (rc < 0) {
        // 处理写入错误
        handle_error_condition();
        release_the_mutex(serial_mutex);
        return;
    }
    // tcdrain(serial_fd); // 对于一些系统，可能需要确保所有数据已发送，再计时或读取

    rc = read(serial_fd, response_mesg, rslen);   /* 使用阻塞模式等待响应 */
    if (rc < 0) {
        // 处理读取错误或超时
        handle_error_condition();
        release_the_mutex(serial_mutex);
        return;
    }

    release_the_mutex(serial_mutex);    /* 释放互斥锁，允许其他线程使用串口 */
    return;   /* 返回接收到的数据在 response_mesg 中 */
}

// 示例调用 (在不同的线程中)
void thread_foo_task() {
    u8 request[] = "foo";
    u8 response[8];
    while (true) {
        serial_messaging(request, sizeof(request), response, sizeof(response));
        // 处理接收到的 response
        sleep(1);
    }
}

void thread_bar_task() {
    u8 request[] = "bar";
    u8 response[8];
    sleep(random_delay());
    serial_messaging(request, sizeof(request), response, sizeof(response));
    // 处理接收到的 response
}
