java中的javap工具及示例

javap 工具是检索特定类或接口信息的有用方法。通过其反汇编功能，javap 命令（也称为 Java 反汇编器）被赋予了为用户提供全面的内部信息的作用。从 -c 或 -verbose 这两个选项中，每个选项都会给出独特的结果，用户能够发现自己处于字节码和字节码编排领域。如果不使用任何选项，javap 会运行输入类的 public、protected 和 package 字段和方法。

语法

javap [option] [classname]

不使用选项时

示例

javap class_name

输出

C:\Users\Aashi>javap java.lang.Object
Compiled from "Object.java"
public class java.lang.Object {
   public java.lang.Object();
   public final native java.lang.Class getClass();
   public native int hashCode();
   public boolean equals(java.lang.Object);
   protected native java.lang.Object clone() throws java.lang.CloneNotSupportedException; public java.lang.String toString();
   public final native void notify();
   public final native void notifyAll();
   public final native void wait (long) throws java.lang.InterruptedException;
   public final void wait(long, int) throws java.lang.InterruptedException;
   public final void wait() throws java.lang.InterruptedException;
   protected void finalize() throws java.lang.Throwable;
   static {};
}

何时使用选项

以下是每个选项以及如何应用它的说明 -

-help 或 --help 或 -? -

这用于打印 javap 命令的帮助消息。

立即学习“Java免费学习笔记（深入）”；

示例

javap -help

输出

C:\Users\Aashi>javap -help
Usage: javap
where possible options include:
-help --help -?      Print this usage message
-version             Version information
-V  -verbose         Print additional information
-1                   Print line number and local variable tables
-public              Show only public classes and members
-protected           Show protected/public classes and members
-package             Show package/protected/public classes and members (default)
-p -private          Show all classes and members
-C                   Disassemble the code
-S                   Print internal type signatures
-sysinfo             Show system info (path, size, date, MD5 hash) of class being processed
-constants           Show final constants
-classpath     Specify where to find user class files
-cp            Specify where to find user class files
-bootclasspath  Override location of bootstrap class files

-版本

用于打印Java的版本信息。

示例

javap -version

输出

C:\Users\Aashi>javap -version
1.8.0_151

-v 或 -verbose -

这用于打印附加信息，例如堆栈大小、局部变量数量和方法参数。

示例

javap -v class_name

输出

C:\Users\Aashi>javap -v java.lang.Object
Classfile jar:file:/C:/Program%20Files/Java/jdk1.8.0_151/jre/lib/rt.jar! /java/lang/Object.class
Last modified Sep 5, 2017; size 1497 bytes
MD5 checksum 074ebc688a81170b8740f1158648a3c7
Compiled from "Object.java"
public class java.lang.Object
minor version: 0
major version: 52
flags: ACC_PUBLIC, ACC_SUPER
Constant pool:
#1 = Integer         999999
#2 - String          #16                //@
#3 = String          #38                //nanosecond timeout value out of range
#4 = String          #42               //timeout value is negative
#5 - Utf8            ()I
#6 = Utf8            ()Ljava/lang/Object;
#7 - Utf8            ()Ljava/lang/String;
#8 = Utf8            ()V
#9 - Utf8            (I)Ljava/lang/String;
#10 - Utf8           (J)V
#11 = Utf8           (JI)V
#12 - Utf8           (Ljava/lang/Object;)Z
#13 = Utf8           (Ljava/lang/String;)V
#14 - Utf8
#15 = Utf8
#16 - Utf8           @
#17 - Utf8           Code
#18 = Utf8           Exceptions
#19 - Utf8           Line Number Table
#20 = Utf8           Signature
#21- Utf8            Source File
#22 = Utf8           StackMapTable
#23 Utf8             Append
#24 Utf8             Clone
#25 = Utf8           Equals
#26 Utf8             finalize
#27 = Utf8           getClass
#28 Utf8             getName
#29 - Utf8           hashCode
#30 = Utf8           java/lang/Class
#31 - Utf8           java/lang/CloneNotSupportedException
#32 = Utf8           java/lang/IllegalArgumentException
#33 - Utf8           Java/lang/Integer
#34 Utf8             java/lang/InterruptedException

-l -

这用于打印行号和局部变量表。

示例

javap -l class_name

输出

C:\Users\Aashi>javap -1 java.lang.Object
Compiled from "Object.java”
public class java.lang.Object {
   public java.lang.Object();
   LineNumberTable:
   line 37: 0

   public final native java.lang.Class getClass();

   public native int hashCode();

   public boolean equals(java.lang.Object);
   LineNumberTable:
   line 149: 0

   protected native java.lang.Object clone() throws java.lang.CloneNotSupportedException;

   public java.lang.String toString();
   LineNumberTable:
   line 236: 0

   public final native void notify();

   public final native void notifyAll();

   public final native void wait(long) throws Java.lang.InterruptedException;
   public final void wait(long, int) throws java.lang.InterruptedException;
   LineNumberTable:
   line 447: 0
   line 448: 6
   line 451: 16
   line 452: 26
   line 456: 36
   line 457: 40
   line 460: 44
   line 461: 49

   public final void wait() throws java.lang.InterruptedException;
   LineNumberTable:
   line 502:0
   line 503: 5
   protected void finalize() throws java.lang.Throwable;
}

-公开

这用于仅打印公共类和成员。

示例

javap -public class_name

输出

C:\Users\Aashi>javap -public java.lang.Object
Compiled from "Object.java"
public class java.lang.Object {
   public java.lang.Object();
   public final native java.lang.Class getClass();
   public native int hashCode();
   public boolean equals(java.lang.Object);
   public java.lang.String toString();
   public final native void notify();
   public final native void notifyAll();
   public final native void wait (long) throws java.lang.InterruptedException; public final void wait (long, int) throws java.lang.InterruptedException; public final void wait() throws java.lang.InterruptedException;
}

-受保护

ASP.NET 4.0电子商城
在现实生活中的购物过程，购物者需要先到商场，找到指定的产品柜台下，查看产品实体以及标价信息，如果产品合适，就将该产品放到购物车中，到收款处付款结算。电子商务网站通过虚拟网页的形式在计算机上摸拟了整个过程，首先电子商务设计人员将产品信息分类显示在网页上，用户查看网页上的产品信息，当用户看到了中意的产品后，可以将该产品添加到购物车，最后使用网上支付工具进行结算，而货物将由公司通过快递等方式发送给购物者

下载

这用于打印受保护/公共类和成员。

示例

javap -protected class_name

输出

C:\Users\Aashi>javap -protected java.lang.Object
Compiled from "Object.java"
public class java.lang.Object {
   public java.lang.Object();
   public final native java.lang.Class getClass();
   public native int hashCode();
   public boolean equals(java.lang.Object);
   protected native java.lang.Object clone() throws java.lang.CloneNotSupportedException;
   public java.lang.String toString();
   public final native void notify();
   public final native void notifyAll();
   public final native void wait(long) throws java.lang.InterruptedException;
   public final void wait (long, int) throws java.lang.InterruptedException;
   public final void wait() throws java.lang.InterruptedException;
   protected void finalize() throws java.lang.Throwable;
}

-包

这用于打印包/受保护/公共类和成员（默认）。

示例

javap -package class_name

输出

C:\Users\Aashi>javap -package java.lang.Object
Compiled from "Object.java"
   public class java.lang.Object {
   public java.lang.Object();
   public final native java.lang.Class getClass();
   public native int hashCode();
   public boolean equals(java.lang.Object);
   protected native java.lang.Object clone() throws java.lang.CloneNotSupportedException;
   public java.lang.String toString();
   public final native void notify();
   public final native void notifyAll();
   public final native void wait (long) throws java.lang.InterruptedException;
   public final void wait (long, int) throws java.lang.InterruptedException;
   public final void wait() throws java.lang.InterruptedException;
   protected void finalize() throws java.lang.Throwable;
   static {};
}

-c

这用于打印反汇编代码。

示例

javap -c class_name

输出

C:\Users\Aashi>javap -c java.lang.Object
Compiled from "Object.java"
public class java.lang.Object (public java.lang.Object();
Code:
0: return
public final native java.lang.Class getClass();

public native int hashCode();

public boolean equals(java.lang.Object);
Code:
0: aload e
1: aload_1
2: 1f_acmpne   9
5:iconst_1
6: goto        10
9: iconst_0
10: ireturn

protected native java.lang.Object clone() throws java.lang.CloneNotSupportedException;

public java.lang.String toString();
Code:
0: new             #52      //class java/lang/StringBuilder
3: dup
4: invokespecial   #74     //Method java/lang/StringBuilder."": ()V
7: aload_e
8: invokevirtual   #73    // Method getClass: ()Ljava/lang/Class;
11: invokevirtual  #67    // Method java/lang/class.getName:()Ljava/lang/String;
14: invokevirtual  #76   // Method java/lang/StringBuilder.append: (Ljava/lang/String;) Ljava/lang/StringBuilder;
17: 1dc            #2    // String @
19: invokevirtual  #76   // Method java/lang/StringBuilder.append: (Ljava/lang/String;)Ljava/lang/StringBuilder;
22: aload_e
23: invokevirtual  #78   // Method hashCode: ()I
26: invokestatic   #69   // Method java/lang/Integer.toHexString: (I) Ljava/lang/String;
29: invokevirtual  #76   // Method java/lang/StringBuilder.append: (Ljava/lang/String;) Ljava/lang/StringBuilder;
32: invokevirtual  #75   // Method java/lang/StringBuilder.toString: ()Ljava/lang/String;
35: areturn
public final native void notify();

-s -

这用于打印内部类型签名。

示例

javap -s class_name

输出

C:\Users\Aashi>javap -s java.lang.Object
Compiled from "Object.java"
public class java.lang.Object {
   public java.lang.Object();
   descriptor: ()V

   public final native java.lang.Class getClass();
   descriptor: ()Ljava/lang/class;

   public native int hashCode();
   descriptor: ()I

   public boolean equals(java.lang.Object);
   descriptor: (Ljava/lang/Object;)Z

   protected native java.lang.Object clone() throws java.lang.CloneNotSupportedException;
   descriptor:()Ljava/lang/Object;

   public java.lang.String toString();
   descriptor: ()Ljava/lang/String;

   public final native void notify();
   descriptor: ()V

   public final native void notifyAll();
   descriptor: ()V

   public final native void wait(long) throws java.lang.InterruptedException; descriptor: (J)V

   public final void wait(long, int) throws java.lang.InterruptedException; descriptor: (JI)V

   public final void wait() throws java.lang.InterruptedException;
   descriptor: ()V
   protected void finalize() throws java.lang.Throwable;
   descriptor: ()V
   static {};
   descriptor: ()V
}

-sysinfo -

这用于打印正在处理的类的系统信息（路径、大小、日期、MD5 哈希）。

示例

javap -sysinfo class_name

输出

C:\Users\Aashi>javap -sysinfo java.lang.Object
Classfile jar:file:/C:/Program%20Files/Java/jdk1.8.0_151/jre/lib/rt.jar! /java/lang/Object.class
Last modified Sep 5, 2017; size 1497 bytes
MD5 checksum 074ebc688a81170b8740f1158648a3c7
Compiled from "Object.java"
public class java.lang.Object {
   public java.lang.Object();
   public final native java.lang.Class getClass();
   public native int hashCode();
   public boolean equals(java.lang.Object);
   protected native java.lang.Object clone() throws java.lang.CloneNotSupportedException;
   public java.lang.String toString();
   public final native void notify();
   public final native void notifyAll();
   public final native void wait (long) throws java.lang.InterruptedException;
   public final void wait (long, int) throws java.lang.InterruptedException;
   public final void wait() throws java.lang.InterruptedException;
   protected void finalize() throws java.lang.Throwable;
   static {};
}

-常量 -

这用于打印类的最终常量。

示例

javap -constants class_name

输出

C:\Users\Aashi>javap -constants java.lang.Object
Compiled from "Object.java"
public class java.lang.Object {

   public java.lang.Object();
   public final native java.lang.Class getClass();
   public native int hashCode();
   public boolean equals(java.lang.Object);
   protected native java.lang.Object clone() throws java.lang.CloneNotSupportedException;
   public java.lang.String toString();
   public final native void notify();
   public final native void notifyAll();
   public final native void wait (long) throws java.lang.InterruptedException;
   public final void wait(long, int) throws java.lang.InterruptedException;
   public final void wait() throws java.lang.InterruptedException;
   protected void finalize() throws java.lang.Throwable;
   static {};
}

结论

javap 工具对于 Java 编码人员来说是一个多方面且非常强大的工具，使他们能够诊断和调试类文档、评估字段和方法以及从类文档的字节码生成清晰的代码。这个不可或缺的工具适合所有技能水平的 Java 开发人员，使他们能够轻松扩展知识并排除 Java 程序故障。对于任何有抱负的程序员来说，javap 工具都是不可替代的财产，它肯定有助于快速提高他们的编程能力。此外，其广泛的功能可以帮助编码人员完善他们的实践，为他们在构建 Java 应用程序时提供竞争优势。

在Java里字符串是如何定义的_String基础用法解析

如何使用取模运算（%）和整数除法分离三位数的各位数字

提取三位数的各位数字：个位、十位与百位的正确分离方法

如何在方法中正确引用领域类（Domain Class）的布尔变量

如何在Java方法中正确引用领域类（Entity）的布尔变量
