『IMAGE-CAPTION』基于CNN-RNN的影像报告生成-PRE

# 解压数据集!unzip  -o  data/data123482/IU数据集.zip -d /home/aistudio/work/

# 取消警告的输出import warnings
warnings.filterwarnings("ignore")

## 制作CSV数据集# 平均字符数为 31.64992700729927import osimport globimport pandas as pdfrom xml.dom import minidomimport reimport numpy as np
LENGTH = []def EmptyDrop(data):
    for i in range(len(data)):        if data.loc[i,'dir'] ==[] or data.loc[i,'caption'] ==[]:            #如果为空，则删除该行
            data.drop([i],axis = 0,inplace = True)
        else:
            data.loc[i,'dir'] = data.loc[i,'dir'][0]
            data.loc[i,'caption'] = data.loc[i,'caption'][0]
    data.reset_index(drop = True,inplace = True)    return datadef clean_text(origin_text):
    # 去掉标点和非法字符
    text = re.sub("^a-zA-Z"," ",origin_text)    #大写改小写
    cleaned_text = text.lower()    return cleaned_textdef xml2csv(path):
    num = 0
    column_name = ['dir','caption']
    xml_csv = pd.DataFrame(columns = column_name)    #图片保存地址
    pic_path =  'work/IU数据集/NLMCXR_png'
    for xml_file in glob.glob(path+'/*.xml'):        #记录每个xml需要保存的所有信息 fx 地址 IMPRESSION FINDINGS
        xml_list = []        #打开xml文档
        dom = minidom.parse(xml_file)        #得到文档元素对象
        root = dom.documentElement        # f1 地址
        itemlists=root.getElementsByTagName('parentImage')        #记录地址
        dirAll = []        for itemlist in itemlists:
            figureId=itemlist.getElementsByTagName('figureId')            #找出该图片的figureID
            figure = figureId[0].childNodes[0].nodeValue            #找出该图片的名称
            ID= itemlist.getAttribute('id')
            IdPath = ID            #正面图&侧面图
            figurePath = [figure+' '+IdPath]
            dirAll.extend(figurePath)
        xml_list.append(dirAll)        #记录FINDINGS and IMPRESSION
        #记录内容
        CaptionAll = []
        itemlists=root.getElementsByTagName('AbstractText')        for i in range(len(itemlists)):
            Label= itemlists[i].getAttribute('Label')            if Label == 'FINDINGS': # or Label == 'IMPRESSION':
                # 内容不为空
                if len(itemlists[i].childNodes)!=0:
                    text = itemlists[i].childNodes[0].nodeValue                    #转小写,过滤无效字符
                    text = clean_text(text)
                    text = text.replace('.','')
                    text = text.replace(',','')
                    text = [text+'']
                    CaptionAll.extend(text)        if len(CaptionAll)>=1:
            LENGTH.append(len(CaptionAll[0].split(' ')))
        xml_list.append(CaptionAll)
        xml_csv.loc[num] = [item for item in xml_list]
        num = num + 1
        print('epoch[{}/{}]'.format(num,len(glob.glob(path+'/*.xml'))))   # print(np.mean(LENGTH))
    return xml_csvdef main():
    xml_path = os.path.join('work','IU数据集','NLMCXR_reports','ecgen-radiology')
    csv = xml2csv(xml_path)
    csv1 = EmptyDrop(csv)
    csv1.to_csv('work/IUxRay.csv',index=None)
if __name__ == '__main__':
    main()

## 使用resnet101预训练模型提取图像特征import paddlefrom paddle.vision.models import resnet101import h5pyimport cv2

csv_file = pd.read_csv('work/IUxRay.csv')
h5_png_file =list(csv_file['dir'])# 创建保存目录save_path = 'work/util_IUxRay'if not os.path.exists(save_path):
    os.makedirs(save_path)# 导入模型resnet101 使用谷歌预训练model = resnet101(pretrained=True)# 删除最后的全连接层del model.fc
model.fc = lambda x:x

h5f = h5py.File(os.path.join(save_path,'resnet101_festures.h5'), 'w')for idx,item in enumerate(h5_png_file):    # 读取所有PNG（F1,F2...）
    print(idx,len(h5_png_file))
    item_all = item.split(',')    for item_t in item_all:
        item_t = item_t.replace('\'','').replace('[','').replace(']','')        # 对不同朝向的图进行区分
        for orie in ['F1','F2','F3','F4']:            if orie in item_t:
                orie_fin = orie
                item_fin = item_t.replace(orie,'').replace(' ','')
                item_fin_png = item_fin + '.png'
                print(orie_fin + '_' + item_fin)                # 读取文件送入模型提取特征并保存为h5
                img = cv2.imread(os.path.join('work/IU数据集/NLMCXR_png',item_fin_png))                # BGR转RGB，且HWC转CHW
                img = img[:,:,::-1].transpose((2,0,1))                # 扩展维度
                img = np.expand_dims(img, 0)
                img_tensor = paddle.to_tensor(img,dtype='float32' ,place=paddle.CUDAPinnedPlace())                # 进行特征提取
                out = model(img_tensor)
                data = out.numpy().astype('float32')                # 保存的数据为h5
                save_path_h5 = data[0]
                h5f.create_dataset(orie_fin + '_' + item_fin, data=save_path_h5)
h5f.close()

# 读取h5文件import h5py
h5f = h5py.File('work/util_IUxRay/resnet101_festures.h5','r')
data = h5f['F1_CXR3027_IM-1402-1001'] # 第一个下划线 之前为图片朝向，之后为图像原命名print(np.array(data).shape) # 每个图片保存为一个2048维度的向量h5f.close()

# 统计训练数据，以单词为粒度创建字典import pandas as pdimport numpy as npimport re

csv_file = pd.read_csv('work/IUxRay.csv')
csv_file.head()

CaptionWordAll = []
CaptionWordLength = []for idx,data_ in enumerate(csv_file.iterrows()):
    caption = data_[1][1]
    CaptionWordLength.append(len(caption.split(' ')))
    CaptionWordAll.extend(caption.split(' '))print('平均句子长度为：',np.mean(CaptionWordLength))print('最大句子长度为：',np.max(CaptionWordLength))print('最小句子长度为：',np.min(CaptionWordLength))print('单词总量为：',len(CaptionWordAll))print('字典长度为：',len(set(CaptionWordAll)))# 100from collections import Counter# 统计频率，按照从高到底排序，这样构建的字典使用频率最高的符号在最前面，查找起来快counts = Counter(CaptionWordAll)
count_sorted = counts.most_common()
count_sorted_ = {k: v for k, v in count_sorted if v > 1}# 构造字典# 增加 <pad> 0 <unk> 1 <start> 2 <end> 3  四个作为常用符号word2id_dict={'<pad>':0,'<unk>':1,'<start>':2,'<end>':3}
id2word_dict={0:'<pad>',1:'<unk>',2:'<start>',3:'<end>'}for idx,item in enumerate(count_sorted_):
    idx_ = idx+4 # 预留四个做为记录
    item_ = item
    word2id_dict[item_] = idx_
    id2word_dict[idx_] = item_# 删除只出现一次的单词print('修正后字典长度为：',len(word2id_dict))

## 完成dataloadimport paddlefrom paddle.io import Datasetimport numpy as npfrom sklearn.model_selection import train_test_split# 重写数据读取类class CaptionDataset(Dataset):
    # 构造函数，定义函数参数
    def __init__(self,csvData,word2id_dict,h5f,maxlength = 40,mode = 'train'):
        self.mode = mode
        self.w2i_dict = word2id_dict
        self.maxlength = maxlength # 输入的最长字符数
        self.padid = 0 # 0为填充符号
        self.h5f = h5f        # 根据train/test 将数据按比例处理
        train,test =csvData.iloc[:int(0.8*len(csvData)),:],csvData.iloc[int(0.8*len(csvData)):,:] #train_test_split(csvData,train_size=0.8,random_state=10)

        if self.mode == 'train':
            train.reset_index(drop=True)
            self.data = train        else:
            test.reset_index(drop=True)
            self.data = test    # 实现__getitem__方法，定义指定index时如何获取数据，并返回单条数据（训练数据，对应的标签）
    def __getitem__(self, index):

        path_name, trg_  = self.data.iloc[index,:]
        # 读取图像的特征
        temp  = path_name.split(' ')
        names = '_'.join(temp)
        img_feature = np.array(self.h5f[names]) # 第一个下划线 之前为图片朝向，之后为图像原命名

        # 输入转成idx
        trg,trg_length = self.generIdxList(trg_) # data
        img_name = temp[-1]        return img_feature,trg,trg_length,img_name    # 实现__len__方法，返回数据集总数目
    def __len__(self):
        return len(self.data)
    def generIdxList(self,tdata):
        # 从输入的String中，生成idx的List
        data = tdata.split(' ')
        data_out = []        # 限制长度，输入'<start>' 和 '<end>'
        data = ['<start>'] + data

        if len(data)>self.maxlength-1:
            data = data[:self.maxlength-1] # 留一个位置给'<end>
            data = data + ['<end>']        else:            # 占位符
            occupy_ = ['<pad>'] * (self.maxlength - 1 - len(data))
            data = data + ['<end>']
            data = data + occupy_        # word 2 index
        for word in data:            if self.w2i_dict.get(word)!= None: # 能找到word
                id_ = self.w2i_dict[word]
                data_out.append(id_)            else:
                id_ = self.w2i_dict['<unk>']
                data_out.append(id_)

        length = len(data_out)-1

        return data_out,lengthdef stackInput(inputs):

    img_features = np.stack([inputsub[0] for inputsub in inputs], axis=0)
    trg = np.stack([inputsub[1] for inputsub in inputs], axis=0)
    trg_length = np.stack([inputsub[2] for inputsub in inputs], axis=0)


    trg_mask =(trg[:,:-1]!=0).astype(paddle.get_default_dtype())
    trg_ = trg[:,1:] # 将start标记更改为 imgfeatures
    return img_features,trg_length,trg_[:,:-1],trg[:,1:,np.newaxis],trg_mask

# 测试数据读取import pandas as pdimport numpy as npimport h5pyfrom sklearn.model_selection import train_test_split
csvData = pd.read_csv('work/IUxRay.csv')
h5f = h5py.File('work/util_IUxRay/resnet101_festures.h5','r')

maxlength = 40dataset=CaptionDataset(csvData,word2id_dict,h5f,maxlength,'train')
data_loader = paddle.io.DataLoader(dataset, batch_size=1,collate_fn = stackInput, shuffle=False)for item in data_loader:    print(item[0].shape,item[1].shape,item[2].shape,item[3].shape,item[4].shape)    break

# 定义模型import paddle.nn as nnimport paddleclass CaptionModel(paddle.nn.Layer):

    def __init__(self, vocab_size,embedding_dim,hidden_size,num_layers,word2id_dict,id2word_dict):

        super(CaptionModel,self).__init__()

        self.hidden_size=hidden_size
        self.num_layers=num_layers
        self.fc = paddle.nn.Linear(2048,embedding_dim)
        self.embedding=paddle.nn.Embedding(vocab_size,embedding_dim)
        self.rnn=paddle.nn.LSTM(input_size=embedding_dim,
                                hidden_size=hidden_size,
                                num_layers=num_layers)
        self.word2ix = word2id_dict
        self.ix2word = id2word_dict
        self.classifier = paddle.nn.Linear(hidden_size,vocab_size)    def forward(self,img_features,trg,trg_length):
        img_features = paddle.unsqueeze(self.fc(img_features),axis = 1)
        embeddings = self.embedding(trg)
        inputs = paddle.concat([img_features,embeddings],axis = 1)
        outputs,state = self.rnn(inputs,sequence_length  = trg_length)
        predict = self.classifier(outputs)        return predict    def generate(self, img_feat, eos_token='<end>',
                 beam_size=2,
                 max_caption_length=40,
                 length_normalization_factor=0.0):
        """
        根据图片生成描述,主要是使用beam search算法以得到更好的描述
        """
        cap_gen = CaptionGenerator(embedder=self.embedding,
                                   rnn=self.rnn,
                                   classifier=self.classifier,
                                   eos_id=self.word2ix[eos_token],
                                   beam_size=beam_size,
                                   max_caption_length=max_caption_length,
                                   length_normalization_factor=length_normalization_factor)

        img_feat = paddle.unsqueeze(img_feat,axis = 0)
        img = paddle.unsqueeze(self.fc(img_feat),axis = 0)

        sentences, score = cap_gen.beam_search(img)

        sentences = [' '.join([self.ix2word[int(idx)] for idx in sent])                     for sent in sentences]        return sentences

# Beam Searchimport paddle.nn as nnimport heapqclass TopN(object):
    """Maintains the top n elements of an incrementally provided set."""

    def __init__(self, n):
        self._n = n
        self._data = []    def size(self):
        assert self._data is not None
        return len(self._data)    def push(self, x):
        """Pushes a new element."""
        assert self._data is not None
        if len(self._data) < self._n:
            heapq.heappush(self._data, x)        else:
            heapq.heappushpop(self._data, x)    def extract(self, sort=False):
        """
        Extracts all elements from the TopN. This is a destructive operation.
        The only method that can be called immediately after extract() is reset().
        Args:
          sort: Whether to return the elements in descending sorted order.
        Returns:
          A list of data; the top n elements provided to the set.
        """
        assert self._data is not None
        data = self._data
        self._data = None
        if sort:
            data.sort(reverse=True)        return data    def reset(self):
        """Returns the TopN to an empty state."""
        self._data = []class Caption(object):
    """Represents a complete or partial caption."""

    def __init__(self, sentence, state, logprob, score, metadata=None):
        """Initializes the Caption.
        Args:
          sentence: List of word ids in the caption.
          state: Model state after generating the previous word.
          logprob: Log-probability of the caption.
          score: Score of the caption.
          metadata: Optional metadata associated with the partial sentence. If not
            None, a list of strings with the same length as 'sentence'.
        """
        self.sentence = sentence
        self.state = state
        self.logprob = logprob
        self.score = score
        self.metadata = metadata    def __cmp__(self, other):
        """Compares Captions by score."""
        assert isinstance(other, Caption)        if self.score == other.score:            return 0
        elif self.score < other.score:            return -1
        else:            return 1

    # For Python 3 compatibility (__cmp__ is deprecated).
    def __lt__(self, other):
        assert isinstance(other, Caption)        return self.score < other.score    # Also for Python 3 compatibility.
    def __eq__(self, other):
        assert isinstance(other, Caption)        return self.score == other.scoreclass CaptionGenerator(object):
    """Class to generate captions from an image-to-text model."""

    def __init__(self,
                 embedder,
                 rnn,
                 classifier,
                 eos_id,
                 beam_size=3,
                 max_caption_length=100,
                 length_normalization_factor=0.0):
        """Initializes the generator.
        Args:
          model: recurrent model, with inputs: (input, state) and outputs len(vocab) values
          beam_size: Beam size to use when generating captions.
          max_caption_length: The maximum caption length before stopping the search.
          length_normalization_factor: If != 0, a number x such that captions are
            scored by logprob/length^x, rather than logprob. This changes the
            relative scores of captions depending on their lengths. For example, if
            x > 0 then longer captions will be favored.
        """
        self.embedder = embedder
        self.rnn = rnn
        self.classifier = classifier
        self.eos_id = eos_id
        self.beam_size = beam_size
        self.max_caption_length = max_caption_length
        self.length_normalization_factor = length_normalization_factor    def beam_search(self, rnn_input, initial_state=None):
        """Runs beam search caption generation on a single image.
        Args:
          initial_state: An initial state for the recurrent model
        Returns:
          A list of Caption sorted by descending score.
        """

        def get_topk_words(embeddings, state):
            output, new_states = self.rnn(embeddings, state)
            output = self.classifier(paddle.squeeze(output,axis=0))
            logprobs = nn.functional.log_softmax(output, axis=-1)            if len(logprobs.shape) == 3:
                logprobs = paddle.squeeze(logprobs)
            logprobs, words = logprobs.topk(self.beam_size, 1)            return words, logprobs, new_states

        partial_captions  = TopN(self.beam_size)
        complete_captions = TopN(self.beam_size)

        words, logprobs, new_state = get_topk_words(rnn_input, initial_state)        for k in range(self.beam_size):
            cap = Caption(
                sentence=[words[0, k]],
                state=new_state,
                logprob=logprobs[0, k],
                score=logprobs[0, k])

            partial_captions.push(cap)        # Run beam search.

        for _ in range(self.max_caption_length - 1):
            partial_captions_list = partial_captions.extract()
            partial_captions.reset()
            input_feed =[c.sentence[-1] for c in partial_captions_list]

            input_feed = paddle.to_tensor(input_feed)
            state_feed = [c.state for c in partial_captions_list]            if isinstance(state_feed[0], tuple):
                state_feed_h, state_feed_c = zip(*state_feed)
                state_feed = (paddle.concat(state_feed_h, 1),
                              paddle.concat(state_feed_c, 1))            else:
                state_feed = paddle.concat(state_feed, 1)


            embeddings = self.embedder(input_feed)

            words, logprobs, new_states = get_topk_words(
                embeddings, state_feed)
            for i, partial_caption in enumerate(partial_captions_list):                if isinstance(new_states, tuple):
                    state = (paddle.slice(new_states[0],axes=[1],starts=[i],ends = [i+1]),
                             paddle.slice(new_states[1],axes=[1],starts=[i],ends = [i+1]))                else:
                    state = new_states[i]                for k in range(self.beam_size):
                    w = words[i, k]
                    sentence = partial_caption.sentence + [w]
                    logprob = partial_caption.logprob + logprobs[i, k]
                    score = logprob                    if w == self.eos_id:                        if self.length_normalization_factor > 0:
                            score /= len(sentence)**self.length_normalization_factor
                        beam = Caption(sentence, state, logprob, score)
                        complete_captions.push(beam)                    else:
                        beam = Caption(sentence, state, logprob, score)
                        partial_captions.push(beam)            if partial_captions.size() == 0:                # We have run out of partial candidates; happens when beam_size
                # = 1.
                break

        # If we have no complete captions then fall back to the partial captions.
        # But never output a mixture of complete and partial captions because a
        # partial caption could have a higher score than all the complete
        # captions.
        if not complete_captions.size():
            complete_captions = partial_captions

        caps = complete_captions.extract(sort=True)        return [c.sentence for c in caps], [c.score for c in caps]

# 定义损失函数class CrossEntropy(paddle.nn.Layer):
    def __init__(self):
        super(CrossEntropy,self).__init__()    def forward(self,pre,real,trg_mask):

        cost=paddle.nn.functional.softmax_with_cross_entropy(logits=pre,label=real)
        # 删除axis=2 shape上为1的维度
        cost=paddle.squeeze(cost,axis=[2])
        # trg_mask 的形状[batch_size,suqence_len]
        masked_cost=cost*trg_mask
        return paddle.mean(paddle.mean(masked_cost,axis=[0]))

# 参数import h5py

epochs=60word_size = 1151eos_id=word2id_dict['<end>']
num_layers=32hidden_size=512embedding_dim=512lr=1e-3maxlength=40model_path='./output'csvData = pd.read_csv('work/IUxRay.csv')
h5f = h5py.File('work/util_IUxRay/resnet101_festures.h5','r')

import paddlenlp

model=CaptionModel(word_size,embedding_dim,hidden_size,num_layers,word2id_dict,id2word_dict)

optimizer=paddle.optimizer.Adam(learning_rate=lr,parameters=model.parameters())# 困惑度ppl_metric=paddlenlp.metrics.Perplexity()


train_dataset=CaptionDataset(csvData,word2id_dict,h5f,maxlength,'train')
train_loader = paddle.io.DataLoader(train_dataset, batch_size=128,collate_fn = stackInput, shuffle=True)

val_dataset=CaptionDataset(csvData,word2id_dict,h5f,maxlength,'test')
val_loader = paddle.io.DataLoader(val_dataset, batch_size=64,collate_fn = stackInput, shuffle=True)# 设置优化器optimizer=paddle.optimizer.Adam(learning_rate=lr,parameters=model.parameters())# 设置损失函数loss_fn = CrossEntropy()

perplexity = paddlenlp.metrics.Perplexity()

model.train()for epoch in range(epochs):    for batch_id, data in enumerate(train_loader()):

        img_features,trg_length,inputs,label,label_mask = data[0],data[1],data[2],data[3], data[4]  # 数据

        predicts = model(img_features,inputs,trg_length)    # 预测结果

        # 计算损失 等价于 prepare 中loss的设置
        loss = loss_fn(predicts, label , label_mask)        # 计算困惑度 等价于 prepare 中metrics的设置
        correct = perplexity.compute(predicts, label)
        perplexity.update(correct.numpy())
        ppl = perplexity.accumulate()
        # 下面的反向传播、打印训练信息、更新参数、梯度清零都被封装到 Model.fit() 中

        # 反向传播
        loss.backward()        if (batch_id+1) % 20 == 0:            print("epoch: {}, batch_id: {}, loss is: {}, ppl is: {}".format(epoch+1, batch_id+1, loss.item(), ppl))            # 保存模型参数，文件名为Unet_model.pdparams
            paddle.save(model.state_dict(), 'work/LSTM_model.pdparams')        # 更新参数
        optimizer.step()        # 梯度清零
        optimizer.clear_grad()

model.eval()for batch_id, data in enumerate(val_loader()):

    img_features,trg_length,inputs,label,label_mask = data[0],data[1],data[2],data[3], data[4]  # 数据

    predicts = model(img_features,inputs,trg_length)    # 预测结果

    # 计算损失 等价于 prepare 中loss的设置
    loss = loss_fn(predicts , label , label_mask)    # 计算困惑度 等价于 prepare 中metrics的设置
    correct = perplexity.compute(predicts, label)
    perplexity.update(correct.numpy())
    ppl = perplexity.accumulate()
    # 下面的反向传播、打印训练信息、更新参数、梯度清零都被封装到 Model.fit() 中

    if (batch_id+1) % 1 == 0:        print(" batch_id: {}, loss is: {}, ppl is: {}".format( batch_id+1, loss.item(), ppl))

# 验证数据集from IPython.display import displayfrom PIL import Imageimport numpy as npfrom tqdm import tqdm

path = 'work/IU数据集/NLMCXR_png/'csvData = pd.read_csv('work/IUxRay.csv')
h5f = h5py.File('work/util_IUxRay/resnet101_festures.h5','r')
data = csvData.iloc[int(0.8*len(csvData)):,:]
scores = []

Beam_Size = 3for idx,data_ in tqdm(enumerate(data.iterrows())):
    F_name = data_[1][0]
    F_text = data_[1][1]

    img_name = F_name.split(' ')[-1]
    h5f_name = '_'.join(F_name.split(' '))
    img_feature = np.array(h5f[h5f_name])
    img_path = path + img_name + '.png'

    img_feature = paddle.to_tensor(img_feature)
    results = model.generate(img_feature,beam_size=Beam_Size)    #print('预测结果：',results[Beam_Size-1])
    #print('正确结果：',F_text)

    #img = Image.open(img_path).convert('RGB')
    #display(img, Image.BILINEAR)

    # 计算BLUE
    from nltk.translate.bleu_score import sentence_bleu
    reference = [F_text.split(' ')]
    candidate = results[Beam_Size-1].split(' ')
    score = sentence_bleu(reference,candidate)
    scores.append(score)print('预测结果：',results[Beam_Size-1])print('正确结果：',F_text)print('BLEU:',np.mean(scores))
img = Image.open(img_path).convert('RGB')
display(img, Image.BILINEAR)
