世界上存在海量的语言与词汇,在处理多语言场景时,传统预训练模型采用的 Vocab 和 Tokenization 方案难免会遇到 Out of Vocabulary 和 Unkonw Token 的情况。 Canine 提供了 tokenization-free 的预训练模型方案,解决了 Out of Vocabulary 问题的同时,提高了模型在多语言任务下的能力。
☞☞☞AI 智能聊天, 问答助手, AI 智能搜索, 免费无限量使用 DeepSeek R1 模型☜☜☜

# 在开始之前,请运行它来切换你的工作目录!import osprint(f"current dir at {os.getcwd()}")if os.getcwd() == '/home/aistudio':
    os.chdir("./work/canine_paddle")    print(f"changing working dir into {os.getcwd()}")current dir at /home/aistudio changing working dir into /home/aistudio/work/canine_paddle
论文链接:CANINE: Pre-training an Efficient Tokenization-Free Encoder for Language Representation
Canine Paddle 复现仓库地址:kevinng77/canine_paddle
【备注】本仓库项目主要对复现操作做整理以及说明,关于更多的 Canine 复现经验和碎碎念分享,欢迎查看 我的博客
本次复现使用 tydiqa 数据集 tydiqa 官方repo,数据处理操作参考了 canine/tydiqa 官方。
TydiQA 为多语言阅读理解数据集。Tydi数据库中包含了 18万+篇 wiki 百科语料,20万+ 文章与问题对,共涉及 11 种不同的语言。
| TydiQA 任务 | TydiQA mBert 基线 | Canine 论文精度 | 本仓库复现精度 |
|---|---|---|---|
| Pas sage Selection Task (SELECTP) | 63.2% | 66.0% | 65.92% |
| Minimal Answer Span Task (MINSPAN) | 51.2% | 52.8% | 55.04% |
指标为macro F1;本仓库展示的复现结果为多次微调、预测、评估后的平均值。
【提示】本章中的 3.3 数据准备 小节存在大量CPU计算,需要占用约3小时+,因此笔者建议想要复现的伙伴在 AiStudio CPU 环境下执行完 3.3 数据准备。而后再切换到 AiStudio GPU 环境下执行剩余部分。
# 复现 TydiQA 任务需要用到 h5py, absl-py 库,更新好 paddlenlp==2.3.1 后,你可能需要重新启动以下 notebook!pip install paddlenlp==2.3.1 h5py absl-py -q
【提示】paddle权重已上传至 data/paddle_weight,使用 model.from_pretrained('data/paddle_weight') 时会自动加载。因此若想直接体验微调流程,可跳过 3.2 模型准备 本章节,直接进入到 3.3 数据准备。 若读者正在复现其他模型,那么这一节或许能够为你提供一些帮助。
【提示】为支持一键运行 notebook,该节中的代码将以 MARKDOWN 形式呈现。请需要运行此节的读者使用终端,并在 work/canine_paddle 目录下运行。
编写模型的 modeling.py 以及 tokenizer.py 文件。 通过阅读和观察 Canine论文及源码,会发现 Canine 模型框架与 Bert 类似,都采用了 Transformer Encoder 作为模型主体。不同的是 Canine:
基于以上四点,模型搭建思路也就很明确了:先参考 paddlenlp/transformers/bert/modeling.py 文件进行修改,实现 Canine 框架的主体,而后分别添加 Hash_Embedding, Local_Attention_Encoder,Projection_Conv 来实现以上四个不同点。
编写后的模型放置于 paddlenlp/transformers/canine/modeling.py
权重转换需要:(只有3.2节会用到,微调时或者在 Aistudio GPU 环境下请勿安装)
pip install transformers==4.19.2 torch==1.11.0
cd ./work/canine_paddle wget -O data/huggingface_weight/model.bin https://huggingface.co/google/canine-s/resolve/main/pytorch_model.bin
根据 huggingface canine 和 我们实现的 canine 框架构造权重映射,具体可查看 reproduction_utils 中的 weight_mapping.py 文件。该步骤生成 torch_paddle_layer_map.json 文件,该文件储存了 Canine 每个 torch Layer 权重对应的 paddle Layer 名称以及形状,方便查看与debug。
运行 convert_weight.py 转换权重:
python -m reproduction_utils.weight_convert_files.convert_weight \ --pytorch_checkpoint_path=data/huggingface_weight/model.bin \ --paddle_dump_path=data/paddle_weight/model_state.pdparams \ --layer_mapping_file=reproduction_utils/weight_convert_files/torch_paddle_layer_map.json
(执行该步需要安装torch与transformers)请在 CPU 环境下进行前项传导核对。
验证过程中,运行 torch canine 模型时会出现 Using unk_token, but it is not set yet. ,属于正常提示。经过多次随机样本验证,paddle模型与huggingface模型精度能保持在 e−5 至 e−7 级别。
python -m reproduction_utils.token_check python -m reproduction_utils.forward_ppg_check --model_dir="./data/paddle_weight"
【提示】 AiStudio 下载速度有时候会很慢,尝试在终止该单元格运行后重新执行看看。运气好下载速度可以达到 3M+/s :)
!wget -O data/tydi/tydiqa-v1.0-dev.jsonl.gz https://storage.googleapis.com/tydiqa/v1.0/tydiqa-v1.0-dev.jsonl.gz !wget -O data/tydi/tydiqa-v1.0-train.jsonl.gz https://storage.googleapis.com/tydiqa/v1.0/tydiqa-v1.0-train.jsonl.gz
【提示】该步骤耗时约4小时,建议在 CPU 环境上运行,数据将保存在 work/canine_paddle/data 文件夹中,因此在切换 AiStudio 环境时不会丢失。详细的数据处理配置请在 tydi_canine 文件夹中查看。
方案一:直接下载并解压处理好的训练和测试数据。
下载后将两个 h5df 数据库放在 data/tydi 目录,如下:
./canine_paddle # 仓库根目录|--data # 仓库数据目录| ├── tydi # tydi数据| ├── dev.h5df # 从tydiqa-v1.0-dev.jsonl.gz提取的测试数据 | ├── train.h5df # 从tydiqa-v1.0-train.jsonl.gz提取的训练数据
你可以考虑将文件保存到自己的百度云盘,而后使用 bypy 库下载到 Aistuio 上。
方案二:处理官方的原数据集
执行以下代码生成测试数据集 dev.h5df,用时约40分钟,生成数据大小2.5GB,包括35万+个样本。
!python3 -m tydi_canine.prepare_tydi_data \ --input_jsonl="**/tydiqa-v1.0-dev.jsonl.gz" \ --output_dir=data/tydi/dev.h5df \ --max_seq_length=2048 \ --doc_stride=512 \ --max_question_length=256 \ --logging_steps=3000 \ --is_training=false
I0624 16:35:16.286553 139650475759360 prepare_tydi_data.py:134] >>> input features will be store at data/tydi/dev.h5df I0624 16:35:16.396667 139650475759360 pd_io.py:53] >>> loading file from data/tydi/tydiqa-v1.0-dev.jsonl.gz I0624 16:35:16.449943 139650475759360 prepare_tydi_data.py:187] Examples processed: 0 I0624 16:39:11.050059 139650475759360 prepare_tydi_data.py:187] Examples processed: 3000 I0624 16:43:06.520539 139650475759360 prepare_tydi_data.py:187] Examples processed: 6000 I0624 16:47:03.243960 139650475759360 prepare_tydi_data.py:187] Examples processed: 9000 I0624 16:51:02.098562 139650475759360 prepare_tydi_data.py:187] Examples processed: 12000 I0624 16:54:55.408642 139650475759360 prepare_tydi_data.py:187] Examples processed: 15000 I0624 16:58:50.746861 139650475759360 prepare_tydi_data.py:187] Examples processed: 18000 I0624 17:00:13.173192 139650475759360 prepare_tydi_data.py:211] Examples with correct context retained: 9212 of 18670 I0624 17:00:13.173460 139650475759360 prepare_tydi_data.py:216] Number of total features 336499 time cose: 24.96 min
!python3 -m tydi_canine.prepare_tydi_data \ --input_jsonl="**/tydiqa-v1.0-train.jsonl.gz" \ --output_dir=data/tydi/train.h5df \ --max_seq_length=2048 \ --doc_stride=512 \ --max_question_length=256 \ --include_unknowns=0.1 \ --logging_steps=30000 \ --is_training=true
I0624 17:00:14.680838 140086686390016 prepare_tydi_data.py:134] >>> input features will be store at data/tydi/train.h5df I0624 17:00:14.683240 140086686390016 pd_io.py:53] >>> loading file from data/tydi/tydiqa-v1.0-train.jsonl.gz I0624 17:00:14.737086 140086686390016 prepare_tydi_data.py:187] Examples processed: 0 I0624 17:36:17.786075 140086686390016 prepare_tydi_data.py:187] Examples processed: 30000 I0624 18:11:26.206844 140086686390016 prepare_tydi_data.py:187] Examples processed: 60000 I0624 18:47:06.246754 140086686390016 prepare_tydi_data.py:187] Examples processed: 90000 I0624 19:22:25.193837 140086686390016 prepare_tydi_data.py:187] Examples processed: 120000 I0624 19:58:38.454844 140086686390016 prepare_tydi_data.py:187] Examples processed: 150000 I0624 20:18:25.707869 140086686390016 prepare_tydi_data.py:211] Examples with correct context retained: 64991 of 166916 I0624 20:18:25.708129 140086686390016 prepare_tydi_data.py:216] Number of total features 459947 time cose: 198.19 min
# 处理完数据后可以将 **/tydiqa-v1.0-train.jsonl.gz 文件删除,之后不需要用到!rm ./data/tydi/tydiqa-v1.0-train.jsonl.gz
from canine import CanineTokenizerfrom canine import CanineModelimport paddle
pretrained_model_path = "data/paddle_weight/"model = CanineModel.from_pretrained(pretrained_model_path)
tokenizer = CanineTokenizer.from_pretrained(pretrained_model_path)
text = ["canine is tokenization-free"]
inputs = tokenizer(text,
                     padding="longest",
                     return_attention_mask=True,
                     return_token_type_ids=True, )
pd_inputs = {k: paddle.to_tensor(v) for (k, v) in inputs.items()}
seq_outputs, pooling_outputs = model(**pd_inputs)print(seq_outputs.shape)print(pooling_outputs.shape)W0624 20:18:29.014458 165 gpu_context.cc:278] Please NOTE: device: 0, GPU Compute Capability: 7.0, Driver API Version: 11.2, Runtime API Version: 10.1 W0624 20:18:29.019143 165 gpu_context.cc:306] device: 0, cuDNN Version: 7.6.
[1, 29, 768] [1, 768]
训练参数信息可在 run_tydi.py 中查看。关于训练的超参、优化器、loss等选择,请查看根目录下的 note.md。
注意: 由于官方论文中并没有提到微调的参数配置,因此本次复现参考并分别尝试了 canine官方仓库 的微调配置(batch_size=512,epoch=10, lr=5e-5),以及 tydiqa 基线仓库 的微调配置(batch_size=16,epoch=3,lr=5e-5)。其中 batch_size=512 通过梯度累加来近似模拟。
实验中发现,10个epoch训练存在明显的过拟合,并且 2-3 个 epoch 的效果普遍比 10 个 epoch 高出 2-3 %。
单卡 V100 32G 训练需要8小时左右(多卡仅改动启动方式为 !python -m paddle.distributed.launch --selected_gpus='0,1,2,3' run_tydi.py)。
# !python -m paddle.distributed.launch --selected_gpus='0,1,2,3' run_tydi.py \ # 多卡训练使用!python run_tydi.py \ --train_input_dir=data/tydi/train.h5df \ --do_train \ --max_seq_length=2048 \ --train_batch_size=20 \ --learning_rate=5e-5 \ --num_train_epochs=2 \ --warmup_proportion=0.1 \ --logging_steps=500 \ --checkout_steps=50000 \ --seed=2022 \ --fp16 \ --gradient_accumulation_steps=1 \ --output_dir=data/tydiqa_baseline_model/train
W0624 20:21:53.680686 27743 gpu_context.cc:278] Please NOTE: device: 0, GPU Compute Capability: 7.0, Driver API Version: 11.2, Runtime API Version: 10.1 W0624 20:21:53.685145 27743 gpu_context.cc:306] device: 0, cuDNN Version: 7.6.[2022-06-24 20:21:58,763] [ INFO] - Weights of CanineForTydiQA not initialized from pretrained model: ['span_classifier.weight', 'span_classifier.bias', 'answer_type_classifier.weight', 'answer_type_classifier.bias'] Found inf or nan, current scale is: 131072.0, decrease to: 131072.0*0.5 Found inf or nan, current scale is: 131072.0, decrease to: 131072.0*0.5 Found inf or nan, current scale is: 131072.0, decrease to: 131072.0*0.5 Found inf or nan, current scale is: 131072.0, decrease to: 131072.0*0.5 Found inf or nan, current scale is: 131072.0, decrease to: 131072.0*0.5 Found inf or nan, current scale is: 131072.0, decrease to: 131072.0*0.5 Found inf or nan, current scale is: 131072.0, decrease to: 131072.0*0.5 Found inf or nan, current scale is: 131072.0, decrease to: 131072.0*0.5 Found inf or nan, current scale is: 131072.0, decrease to: 131072.0*0.5 Found inf or nan, current scale is: 131072.0, decrease to: 131072.0*0.5 Found inf or nan, current scale is: 131072.0, decrease to: 131072.0*0.5 Found inf or nan, current scale is: 131072.0, decrease to: 131072.0*0.5
训练日志在 work/canine_paddle/data/tydiqa_baseline_model/trian 中可以查看。同时可以使用 Paddle 的 VisualDL 可视化工具查看:1. 选择 notebook 左侧的数据模型可视化。2. 添加 /home/aistudio/log/train 目录为 logdir
【备注】测评环节根据 tydi 官方 指示进行。 我们使用训练结束的权重进行测试,不考虑中间的checkout point。 测评过程中会生成./data/tydiqa_baseline_model/predict/pred.jsonl ,其为格式满足 TydiQA 评测要求的文件,格式要求可以参考:TydiQA 评测文件示例
步骤一: 运行以下代码,生成任务评测文件 pred.jsonl ,由于 tydiQA任务的评估方式较为特殊,因此可以采用单卡或者多卡进行(多卡仅改动启动方式为 !python -m paddle.distributed.launch --selected_gpus='0,1,2,3' run_tydi.py):
# !python3 -m paddle.distributed.launch --selected_gpus='0,1,2,3' run_tydi.py \ # 多卡训练使用!python3 run_tydi.py \ --state_dict_path=data/tydiqa_baseline_model/train \ --predict_file=data/tydi/tydiqa-v1.0-dev.jsonl.gz \ --precomputed_predict_file=data/tydi/dev.h5df \ --do_predict \ --max_seq_length=2048 \ --max_answer_length=100 \ --candidate_beam=30 \ --predict_batch_size=32 \ --logging_steps=1000 \ --seed=2022 \ --output_dir=data/tydiqa_baseline_model/predict \ --output_prediction_file=data/tydiqa_baseline_model/predict/pred.jsonl
W0625 03:29:33.173774 13821 gpu_context.cc:278] Please NOTE: device: 0, GPU Compute Capability: 7.0, Driver API Version: 11.2, Runtime API Version: 10.1 W0625 03:29:33.178153 13821 gpu_context.cc:306] device: 0, cuDNN Version: 7.6.[2022-06-25 03:29:38,250] [ INFO] - Weights of CanineForTydiQA not initialized from pretrained model: ['span_classifier.weight', 'span_classifier.bias', 'answer_type_classifier.weight', 'answer_type_classifier.bias']
测评日志在 work/canine_paddle/data/tydiqa_baseline_model/predict 中可以查看。
超参说明:
--state_dict_path:存放微调权重的文件路径;若为文件夹路径,则会读取该文件夹下的 tydi_seed_{seed}.pdparams 权重。
--predict_file:从官方下载的 tydiqa-v1.0-dev.jsonl.gz 文件路径。
--output_dir:输出运行日志
--output_prediction_file:输出 JSON 评估文件路径。
步骤二: 运行 tydi 官方跑分程序:将 predictions_path 对应到上一步中的 pred.jsonl 位置。
其中 Tydi 测评所需要的 tydi_eval.py, eval_utils.py 源于 tydi 官方。
运行下方代码,可以看到,仅训练 2个 Epoch(官方仓库的配置是10个epoch),CANINE 在 TydiQA 数据集上的指标均比 Tydi mBert 基线高出了3%+。
!python3 official_tydi/tydi_eval.py \ --gold_path=data/tydi/tydiqa-v1.0-dev.jsonl.gz \ --predictions_path=data/tydiqa_baseline_model/predict/pred.jsonl \ --verbose=False
I0625 09:06:43.232116 140451243751168 eval_utils.py:291] Parsing data/tydi/tydiqa-v1.0-dev.jsonl.gz (gzip)...
I0625 09:06:50.419521 140451243751168 tydi_eval.py:479] 7556 examples have minimal answers
I0625 09:06:50.419761 140451243751168 tydi_eval.py:480] ****************************************
I0625 09:06:50.419822 140451243751168 eval_utils.py:211] Reading predictions from file: data/tydiqa_baseline_model/predict/pred.jsonl
W0625 09:06:50.718449 140451243751168 tydi_eval.py:233] Predictions missing for 1 examples.
I0625 09:06:50.718697 140451243751168 tydi_eval.py:234]   Missing ids: [483185134238717036]
Passage & english & \fpr{61.9}{66.2}{58.1}
Minimal Answer & english & \fpr{49.9}{61.6}{41.9}
********************
Passage & arabic & \fpr{83.0}{85.2}{80.9}
Minimal Answer & arabic & \fpr{70.7}{80.0}{63.4}
********************
Passage & bengali & \fpr{65.1}{74.7}{57.7}
Minimal Answer & bengali & \fpr{54.3}{62.7}{47.8}
********************
Passage & finnish & \fpr{64.1}{65.5}{62.8}
Minimal Answer & finnish & \fpr{56.1}{63.5}{50.2}
********************
W0625 09:06:50.812115 140451243751168 tydi_eval.py:233] Predictions missing for 1 examples.
I0625 09:06:50.812309 140451243751168 tydi_eval.py:234]   Missing ids: [15806027368664557]
Passage & indonesian & \fpr{64.7}{66.0}{63.5}
Minimal Answer & indonesian & \fpr{56.6}{61.7}{52.3}
********************
Passage & japanese & \fpr{52.8}{65.6}{44.2}
Minimal Answer & japanese & \fpr{44.5}{55.0}{37.4}
********************
Passage & swahili & \fpr{68.9}{76.5}{62.7}
Minimal Answer & swahili & \fpr{60.7}{74.7}{51.1}
********************
Passage & korean & \fpr{63.1}{71.1}{56.7}
Minimal Answer & korean & \fpr{39.0}{43.8}{35.2}
********************
Passage & russian & \fpr{64.6}{65.1}{64.1}
Minimal Answer & russian & \fpr{50.2}{61.3}{42.5}
********************
W0625 09:06:50.966964 140451243751168 tydi_eval.py:233] Predictions missing for 2 examples.
I0625 09:06:50.967158 140451243751168 tydi_eval.py:234]   Missing ids: [-6397488112403382620, 7216454742149172827]
Passage & telugu & \fpr{83.5}{83.6}{83.4}
Minimal Answer & telugu & \fpr{77.5}{86.3}{70.3}
********************
Passage & thai & \fpr{62.4}{64.9}{60.1}
Minimal Answer & thai & \fpr{49.8}{55.1}{45.5}
********************
Total # examples in gold: 18670, # ex. in pred: 18666 (including english)
*** Macro Over 10 Languages, excluding English **
Passage F1:0.672 P:0.718 R:0.635978
\fpr{67.2}{71.8}{63.6}
Minimal F1:0.560 P:0.644 R:0.495881
\fpr{56.0}{64.4}{49.6}
*** / Aggregate Scores ****
{"avg_passage_f1": 0.672270647476107, "avg_passage_recall": 0.6359777874965081, "avg_passage_precision": 0.7183519530345681, "avg_minimal_f1": 0.5595748224545292, "avg_minimal_recall": 0.4958814852655177, "avg_minimal_precision": 0.6441669216190516}--gold_path:从官方下载的 tydiqa-v1.0-dev.jsonl.gz 文件路径。
--predictions_path:步骤一种输出 JSON 评估文件的路径。 步骤三: 清理过程文件
在 data/tydiqa_baseline_model/predict 文件夹下会生成用于储存 logits 的 results_gpu_*.pickle 文件。测试结束后可以将其删除。
# 删除预测中的过程文件!rm -r `find ./data -name "results_gpu_*"`
以下复现结果为多次微调、预测、评估后的 macro F1 平均值:
| TydiQA 任务 | TydiQA mBert 基线 | Canine 论文精度 | 本仓库复现精度 |
|---|---|---|---|
| Passage Selection Task (SELECTP) | 63.2% | 66.0% | 65.92% |
| Minimal Answer Span Task (MINSPAN) | 51.2% | 52.8% | 55.04% |
各次微调的日志、评估文件等可以在 logs 文件夹中查看,这边对所有训练结果进行整理:
| batch size | acc grad steps | 理论 batch size | seed | epoch | TydiQA SelectP F1 | TydiQA MinSpan F1 | |
|---|---|---|---|---|---|---|---|
| V100 | 16 | 1 | 16 | 2021 | 3 | 66.01% | 55.77% |
| V100 | 16 | 1 | 16 | 666 | 3 | 67.02% | 56.17% |
| v100 | 16 | 32 | 512 | 5121 | 10 | 64.35% | 53.58% |
| v100 | 16 | 32 | 512 | 555 | 4 | 66.29% | 54.12% |
| 3090*4 | 14 | 9 | 504 | 5123 | 4 | 65.93% | 55.60% |
| - | - | - | - | 平均 | 65.92% | 55.04% |
此外,以下展示了 所有 复现过程中进行过的其他微调结果,由于参数配置问题,他们不被计入论文复现精度,但仍可以为该模型在Tydi任务上的训练效果提供一些信息。
| 设备 | batch size | acc grad steps | 理论 batch size | seed | 混合精度训练 | epoch | warm up | TydiQA SelectP F1 | TydiQA MinSpan F1 |
|---|---|---|---|---|---|---|---|---|---|
| V100*1 | 20 | 25 | 500 | 6 | 否 | 10 | 0.01 | 64.38% | 53.73% |
| 3090*4 | 10 | 12 | 480 | 6 | 否 | 10 | 0.01 | 65.23% | 53.49% |
| 3090*4 | 10 | 1 | 40 | 6 | 否 | 10 | 0.01 | 67.31% | 53.11% |
| V100*4 | 16 | 1 | 64 | 2022 | 是 | 3 | 0.01 | 67.26% | 56.41% |
| V100*4 | 16 | 1 | 64 | 2020 | 是 | 3 | 0.01 | 67.29% | 56.42% |
| V100*4 | 8 | 1 | 32 | 2020 | 是 | 3 | 0.1 | 67.26% | 56.37% |
| A4000*4 | 8 | 1 | 32 | 2020 | 是 | 3 | 0.1 | 67.43% | 55.91% |
| - | - | - | - | - | - | - | 平均 | 66.59% | 55.06% |
备注:
