工业蒸汽量预测

1. 引言

1.1 项目介绍

  • 火力发电的基本原理是:燃料在燃烧时加热水生成蒸汽,蒸汽压力推动汽轮机旋转,然后汽轮机带动发电机旋转,产生电能。在这一系列的能量转化中,影响发电效率的核心是锅炉的燃烧效率,即燃料燃烧加热水产生高温高压蒸汽。锅炉的燃烧效率的影响因素很多,包括锅炉的可调参数,如燃烧给量,一二次风,引风,返料风,给水水量;以及锅炉的工况,比如锅炉床温、床压,炉膛温度、压力,过热器的温度等。
  • 本项目使用人工神经网络完成蒸汽量回归预测,包括数据处理、异常值处理、相关性分析、模型构建、模型训练、模型预测等步骤。

1.2 数据集介绍

经脱敏后的锅炉传感器采集的数据(采集频率是分钟级别),根据锅炉的工况,预测产生的蒸汽量。

数据集各个字段以及数据类型如下所示:

  • 数据集特征较多,需要筛选有用特征
  • 数据集最后一列为需要预测的目标值
  • 除最后一列外的数据列都是特征
V0 V1 V2 V3 V4 V5 V6 V7 V8 V9 ... V36 V37 target
float float float float float float float float float float float float float float

2. 环境准备

2.1 安装环境

In [ ]
pip install missingno -q
登录后复制

Note: you may need to restart the kernel to use updated packages.
登录后复制


2.2 导入所需模块

In [1]
import numpy as np
import pandas as pd
import matplotlib.pyplot as pltimport seaborn as snsimport missingno as msnofrom sklearn.model_selection import train_test_splitfrom sklearn.preprocessing import StandardScalerfrom sklearn.pipeline import Pipelinefrom sklearn.linear_model import LogisticRegressionfrom sklearn.tree import DecisionTreeClassifierfrom sklearn.ensemble import GradientBoostingClassifierfrom sklearn.ensemble import RandomForestClassifierfrom sklearn.neighbors import KNeighborsClassifier

from sklearn.model_selection import GridSearchCVfrom sklearn.model_selection import cross_val_scorefrom sklearn.metrics import confusion_matrix, classification_report, accuracy_scorefrom sklearn import metricsfrom sklearn.metrics import roc_curve, auc, roc_auc_score
登录后复制


3. 数据处理

3.1 读取数据

In [2]
IndustrialSteam_train=pd.read_csv(r'data/data178496/zhengqi_train.txt',sep='\t')
IndustrialSteam_test=pd.read_csv(r'data/data178496/zhengqi_test.txt',sep='\t')
登录后复制

In [ ]
IndustrialSteam_train.head()
登录后复制

      V0     V1     V2     V3     V4     V5     V6     V7     V8     V9  ...  \
0  0.566  0.016 -0.143  0.407  0.452 -0.901 -1.812 -2.360 -0.436 -2.114  ...
1  0.968  0.437  0.066  0.566  0.194 -0.893 -1.566 -2.360  0.332 -2.114  ...
2  1.013  0.568  0.235  0.370  0.112 -0.797 -1.367 -2.360  0.396 -2.114  ...
3  0.733  0.368  0.283  0.165  0.599 -0.679 -1.200 -2.086  0.403 -2.114  ...
4  0.684  0.638  0.260  0.209  0.337 -0.454 -1.073 -2.086  0.314 -2.114  ...

     V29    V30    V31    V32    V33    V34    V35    V36    V37  target
0  0.136  0.109 -0.615  0.327 -4.627 -4.789 -5.101 -2.608 -3.508   0.175
1 -0.128  0.124  0.032  0.600 -0.843  0.160  0.364 -0.335 -0.730   0.676
2 -0.009  0.361  0.277 -0.116 -0.843  0.160  0.364  0.765 -0.589   0.633
3  0.015  0.417  0.279  0.603 -0.843 -0.065  0.364  0.333 -0.112   0.206
4  0.183  1.078  0.328  0.418 -0.843 -0.215  0.364 -0.280 -0.028   0.384

[5 rows x 39 columns]
登录后复制


3.2 数据分析及可视化

3.2.1 缺失值检测

  • 所有属性中有2888个非空值,因此没有丢失值。
  • 所有功能的数据类型都是float64,可以传入模型,无需进行数据类型转换。
In [ ]
IndustrialSteam_train.info()
登录后复制


3.2.2 缺失值可视化

In [ ]
missing_values = msno.bar(IndustrialSteam_train, figsize = (16,5),color = "#483D8B")
登录后复制

<Figure size 1600x500 with 3 Axes>
登录后复制


3.2.3 描述统计

In [ ]
IndustrialSteam_train.describe().T
登录后复制

         count      mean       std     min      25%     50%      75%    max
V0      2888.0  0.123048  0.928031  -4.335 -0.29700  0.3590  0.72600  2.121
V1      2888.0  0.056068  0.941515  -5.122 -0.22625  0.2725  0.59900  1.918
V2      2888.0  0.289720  0.911236  -3.420 -0.31300  0.3860  0.91825  2.828
V3      2888.0 -0.067790  0.970298  -3.956 -0.65225 -0.0445  0.62400  2.457
V4      2888.0  0.012921  0.888377  -4.742 -0.38500  0.1100  0.55025  2.689
V5      2888.0 -0.558565  0.517957  -2.182 -0.85300 -0.4660 -0.15400  0.489
V6      2888.0  0.182892  0.918054  -4.576 -0.31000  0.3880  0.83125  1.895
V7      2888.0  0.116155  0.955116  -5.048 -0.29500  0.3440  0.78225  1.918
V8      2888.0  0.177856  0.895444  -4.692 -0.15900  0.3620  0.72600  2.245
V9      2888.0 -0.169452  0.953813 -12.891 -0.39000  0.0420  0.04200  1.335
V10     2888.0  0.034319  0.968272  -2.584 -0.42050  0.1570  0.61925  4.830
V11     2888.0 -0.364465  0.858504  -3.160 -0.80325 -0.1120  0.24700  1.455
V12     2888.0  0.023177  0.894092  -5.165 -0.41900  0.1230  0.61600  2.657
V13     2888.0  0.195738  0.922757  -3.675 -0.39800  0.2895  0.86425  2.475
V14     2888.0  0.016081  1.015585  -2.455 -0.66800 -0.1610  0.82975  2.558
V15     2888.0  0.096146  1.033048  -2.903 -0.66225 -0.0005  0.73000  4.314
V16     2888.0  0.113505  0.983128  -5.981 -0.30000  0.3060  0.77425  2.861
V17     2888.0 -0.043458  0.655857  -2.224 -0.36600  0.1650  0.43000  2.023
V18     2888.0  0.055034  0.953466  -3.582 -0.36750  0.0820  0.51325  4.441
V19     2888.0 -0.114884  1.108859  -3.704 -0.98750 -0.0005  0.73725  3.431
V20     2888.0 -0.186226  0.788511  -3.402 -0.67550 -0.1565  0.30400  3.525
V21     2888.0 -0.056556  0.781471  -2.643 -0.51700 -0.0565  0.43150  2.259
V22     2888.0  0.302893  0.639186  -1.375 -0.06300  0.2165  0.87200  2.018
V23     2888.0  0.155978  0.978757  -5.542  0.09725  0.3380  0.36825  1.906
V24     2888.0 -0.021813  1.033403  -1.344 -1.19100  0.0950  0.93125  2.423
V25     2888.0 -0.051679  0.915957  -3.808 -0.55725 -0.0760  0.35600  7.284
V26     2888.0  0.072092  0.889771  -5.131 -0.45200  0.0750  0.64425  2.980
V27     2888.0  0.272407  0.270374  -1.164  0.15775  0.3250  0.44200  0.925
V28     2888.0  0.137712  0.929899  -2.435 -0.45500 -0.4470  0.73000  4.671
V29     2888.0  0.097648  1.061200  -2.912 -0.66400 -0.0230  0.74525  4.580
V30     2888.0  0.055477  0.901934  -4.507 -0.28300  0.0535  0.48800  2.689
V31     2888.0  0.127791  0.873028  -5.859 -0.17025  0.2995  0.63500  2.013
V32     2888.0  0.020806  0.902584  -4.053 -0.40725  0.0390  0.55700  2.395
V33     2888.0  0.007801  1.006995  -4.627 -0.49900 -0.0400  0.46200  5.465
V34     2888.0  0.006715  1.003291  -4.789 -0.29000  0.1600  0.27300  5.110
V35     2888.0  0.197764  0.985675  -5.695 -0.20250  0.3640  0.60200  2.324
V36     2888.0  0.030658  0.970812  -2.608 -0.41300  0.1370  0.64425  5.238
V37     2888.0 -0.130330  1.017196  -3.630 -0.79825 -0.1855  0.49525  3.000
target  2888.0  0.126353  0.983966  -3.044 -0.35025  0.3130  0.79325  2.538
登录后复制


3.2.4 样本特征分布可视化

In [ ]
hist_plot = IndustrialSteam_train.hist(figsize = (20,20), color = "#483D8B")
登录后复制

<Figure size 2000x2000 with 42 Axes>
登录后复制


3.2.5 相关性分析

  • 用于查看特征与特征之间的相关性
  • 查看目标值与特征之间的相关性
  • 筛选出与目标值有较强相关性的特征
In [ ]
from pylab import mplfrom matplotlib.font_manager import FontProperties
myfont=FontProperties(fname=r'/usr/share/fonts/fangzheng/FZSYJW.TTF',size=12)
sns.set(font=myfont.get_name())

corr = IndustrialSteam_train.corr()# 调用热力图绘制相关性关系plt.figure(figsize=(25,25),dpi=150)
sns.heatmap(corr, square=True, linewidths=0.1, annot=True)
登录后复制

<matplotlib.axes._subplots.AxesSubplot at 0x7fe003667410>
登录后复制

<Figure size 3750x3750 with 2 Axes>
登录后复制


3.2.6 筛选特征

以0.5为界限,同时在训练集和测试集中去除相关系数绝对值低于0.5的特征,确保被输入模型进行训练的特征与预测目标值有较强的相关性。

In [3]
df_train = IndustrialSteam_train[['V0','V1','V3','V4','V8','V12','V16','V31','target']]
df_test = IndustrialSteam_test[['V0','V1','V3','V4','V8','V12','V16','V31']]
登录后复制


3.3 异常值处理

3.3.1 异常值检测

  • 使用箱型图查看离群点(Outlier)
  • 对于离群点考虑使用异常值处理方法
In [ ]
plt.figure(figsize=(20,10))
sns.boxenplot(data = df_train)
plt.xticks(rotation=60)
plt.show()
登录后复制

<Figure size 2000x1000 with 1 Axes>
登录后复制


3.3.2 异常值插补

  • 与缺失值的插补一样,我们也可以插补异常值。
  • 我们可以在这种方法中使用均值、中值和零值来插补。
  • 由于我们进行了填补,而不是直接删除异常值。因此不会丢失数据。
  • 这里的中值是合适的,因为它不受异常值的影响。
In [ ]
#median imputationimport pandas as pdimport numpy as np
train = df_train
sns.boxplot(train['V0'])
plt.title("Box Plot before median imputation")
plt.show()
q1 = train['V0'].quantile(0.25)
q3 = train['V0'].quantile(0.75)
iqr = q3-q1
Lower_tail = q1 - 1.5 * iqr
Upper_tail = q3 + 1.5 * iqr# V0med = np.median(train['V0'])for i in train['V0']:    if i > Upper_tail or i < Lower_tail:
            train['V0'] = train['V0'].replace(i, med)
sns.boxplot(train['V0'])
plt.title("Box Plot after median imputation")
plt.show()

# V1med = np.median(train['V1'])for i in train['V1']:    if i > Upper_tail or i < Lower_tail:
            train['V1'] = train['V1'].replace(i, med)# V3med = np.median(train['V3'])for i in train['V3']:    if i > Upper_tail or i < Lower_tail:
            train['V3'] = train['V3'].replace(i, med)# V4med = np.median(train['V4'])for i in train['V4']:    if i > Upper_tail or i < Lower_tail:
            train['V4'] = train['V4'].replace(i, med)# V8med = np.median(train['V8'])for i in train['V8']:    if i > Upper_tail or i < Lower_tail:
            train['V8'] = train['V8'].replace(i, med)# V12med = np.median(train['V12'])for i in train['V12']:    if i > Upper_tail or i < Lower_tail:
            train['V12'] = train['V12'].replace(i, med)# V16med = np.median(train['V16'])for i in train['V16']:    if i > Upper_tail or i < Lower_tail:
            train['V16'] = train['V16'].replace(i, med)# V31med = np.median(train['V31'])for i in train['V31']:    if i > Upper_tail or i < Lower_tail:
            train['V31'] = train['V31'].replace(i, med)
登录后复制

<Figure size 640x480 with 1 Axes>
登录后复制

/opt/conda/envs/python35-paddle120-env/lib/python3.7/site-packages/ipykernel_launcher.py:18: SettingWithCopyWarning:
A value is trying to be set on a copy of a slice from a DataFrame.
Try using .loc[row_indexer,col_indexer] = value instead

See the caveats in the documentation: https://pandas.pydata.org/pandas-docs/stable/user_guide/indexing.html#returning-a-view-versus-a-copy
登录后复制

<Figure size 640x480 with 1 Axes>
登录后复制

/opt/conda/envs/python35-paddle120-env/lib/python3.7/site-packages/ipykernel_launcher.py:27: SettingWithCopyWarning:
A value is trying to be set on a copy of a slice from a DataFrame.
Try using .loc[row_indexer,col_indexer] = value instead

See the caveats in the documentation: https://pandas.pydata.org/pandas-docs/stable/user_guide/indexing.html#returning-a-view-versus-a-copy
/opt/conda/envs/python35-paddle120-env/lib/python3.7/site-packages/ipykernel_launcher.py:33: SettingWithCopyWarning:
A value is trying to be set on a copy of a slice from a DataFrame.
Try using .loc[row_indexer,col_indexer] = value instead

See the caveats in the documentation: https://pandas.pydata.org/pandas-docs/stable/user_guide/indexing.html#returning-a-view-versus-a-copy
/opt/conda/envs/python35-paddle120-env/lib/python3.7/site-packages/ipykernel_launcher.py:39: SettingWithCopyWarning:
A value is trying to be set on a copy of a slice from a DataFrame.
Try using .loc[row_indexer,col_indexer] = value instead

See the caveats in the documentation: https://pandas.pydata.org/pandas-docs/stable/user_guide/indexing.html#returning-a-view-versus-a-copy
/opt/conda/envs/python35-paddle120-env/lib/python3.7/site-packages/ipykernel_launcher.py:45: SettingWithCopyWarning:
A value is trying to be set on a copy of a slice from a DataFrame.
Try using .loc[row_indexer,col_indexer] = value instead

See the caveats in the documentation: https://pandas.pydata.org/pandas-docs/stable/user_guide/indexing.html#returning-a-view-versus-a-copy
/opt/conda/envs/python35-paddle120-env/lib/python3.7/site-packages/ipykernel_launcher.py:51: SettingWithCopyWarning:
A value is trying to be set on a copy of a slice from a DataFrame.
Try using .loc[row_indexer,col_indexer] = value instead

See the caveats in the documentation: https://pandas.pydata.org/pandas-docs/stable/user_guide/indexing.html#returning-a-view-versus-a-copy
/opt/conda/envs/python35-paddle120-env/lib/python3.7/site-packages/ipykernel_launcher.py:57: SettingWithCopyWarning:
A value is trying to be set on a copy of a slice from a DataFrame.
Try using .loc[row_indexer,col_indexer] = value instead

See the caveats in the documentation: https://pandas.pydata.org/pandas-docs/stable/user_guide/indexing.html#returning-a-view-versus-a-copy
/opt/conda/envs/python35-paddle120-env/lib/python3.7/site-packages/ipykernel_launcher.py:63: SettingWithCopyWarning:
A value is trying to be set on a copy of a slice from a DataFrame.
Try using .loc[row_indexer,col_indexer] = value instead

See the caveats in the documentation: https://pandas.pydata.org/pandas-docs/stable/user_guide/indexing.html#returning-a-view-versus-a-copy
登录后复制


查看异常值插补后的数据分布

In [ ]
plt.figure(figsize=(20,10))
sns.boxenplot(data = df_train)
plt.xticks(rotation=60)
plt.show()
登录后复制

<Figure size 2000x1000 with 1 Axes>
登录后复制


3.4 数据预处理

3.4.1 拆分特征数据与目标值数据

  • 选择'V0','V1','V3','V4','V8','V12','V16','V31'字段作为特征
  • 选择'target'字段作为目标值
In [4]
data_features = df_train.loc[df_train.index[:], ['V0','V1','V3','V4','V8','V12','V16','V31']]
data_label = df_train['target']
登录后复制


3.4.2 划分数据集

  • 按照0.8:0.2的比例划分训练集与测试集
In [5]
from sklearn.model_selection import train_test_split# 数据集划分x_train, x_test, y_train, y_test = train_test_split(data_features, data_label, test_size=0.2, random_state=6)print("训练集的特征值:\n",  x_train.shape)print("测试集的标签值:\n",  y_test.shape)print("The length of original data X is:", data_features.shape[0])print("The length of train Data is:", x_train.shape[0])print("The length of test Data is:", x_test.shape[0])
登录后复制

训练集的特征值:
 (2310, 8)
测试集的标签值:
 (578,)
The length of original data X is: 2888
The length of train Data is: 2310
The length of test Data is: 578
登录后复制


3.4.3 重置索引

对于数据集索引进行重置,确保所有数据都从第0条开始排序

商汤商量
商汤商量

商汤科技研发的AI对话工具,商量商量,都能解决。

商汤商量 36
查看详情 商汤商量
In [6]
x_train=x_train.reset_index(drop=True)
x_test=x_test.reset_index(drop=True)
y_train=y_train.reset_index(drop=True)
y_test=y_test.reset_index(drop=True)
登录后复制


3.4.4 转换数组

对重置完成的各个数据集,将数据转换成矩阵形式供后续使用。

In [7]
x_train=np.array(x_train)
x_test=np.array(x_test)
y_train=np.array(y_train)
y_test=np.array(y_test)
登录后复制

In [ ]
y_train
登录后复制

array([-0.987,  1.142, -2.555, ..., -0.42 ,  1.024,  1.046])
登录后复制

In [8]
y_train = np.array(y_train)
y_train = y_train.reshape(-1,1)

y_test = np.array(y_test)
y_test = y_test.reshape(-1,1)
登录后复制


3. 5 归一化(标准化)

  • 对训练集与测试集进行归一化或者标准化处理
  • 本处我们选择标准化
In [ ]
from sklearn.preprocessing import MinMaxScalerfrom sklearn.preprocessing import StandardScaler# 1. 实例化一个转换器类transfer = StandardScaler()# 2. 标准化x_train = transfer.fit_transform(x_train)
x_test = transfer.fit_transform(x_test)

y_train = transfer.fit_transform(y_train)
y_test = transfer.fit_transform(y_test)# df_test_x = transfer.fit_transform(df_test)
登录后复制

In [ ]
x_train[0]
登录后复制

array([-0.187, -0.33 , -1.523,  0.6  , -0.437,  0.389, -0.626, -0.057])
登录后复制


3.6 设置随机数种子

In [ ]
import randomimport paddle

seed = 666# 设置随机种子 固定结果def set_seed(seed):
    np.random.seed(seed)
    random.seed(seed)
    paddle.seed(seed)

set_seed(seed)
登录后复制


4. 模型构建

搭建全连接神经网络

  • 8节点输入
  • 1输出节点
In [9]
import paddleimport paddle.nn as nn# 定义动态图class Classification(paddle.nn.Layer):
    def __init__(self):
        super(Classification, self).__init__()
        self.fc1 = paddle.nn.Linear(8, 1)
    # 网络的前向计算函数
    def forward(self, inputs):
        pred = self.fc1(inputs)        return pred
登录后复制


5. 可视化损失函数

In [11]
train_nums = []
train_costs = []def draw_train_process(iters,train_costs):
    title="training cost"
    plt.title(title, fontsize=24)
    plt.xlabel("iter", fontsize=14)
    plt.ylabel("cost", fontsize=14)
    plt.plot(iters, train_costs,color='red',label='training cost')
    plt.grid()
    plt.show()
登录后复制


6. 自定义损失函数

In [20]
import paddleimport paddle.nn.functional as Fclass kl_loss(paddle.nn.Layer):
    def __init__(self):
       super(kl_loss, self).__init__()    def forward(self, p, q, label):
        ce_loss = 0.5 * (F.mse_loss(p, label=label)) + F.mse_loss(q, label=label)
        kl_loss = self.compute_kl_loss(p, q)        # carefully choose hyper-parameters
        loss = ce_loss + 0.3 * kl_loss

        return loss    def compute_kl_loss(self, p, q):

        p_loss = F.kl_div(F.log_softmax(p, axis=-1), F.softmax(q, axis=-1), reduction='none')
        q_loss = F.kl_div(F.log_softmax(q, axis=-1), F.softmax(p, axis=-1), reduction='none')        # You can choose whether to use function "sum" and "mean" depending on your task
        p_loss = p_loss.sum()
        q_loss = q_loss.sum()

        loss = (p_loss + q_loss) / 2

        return loss
登录后复制


7. 模型训练

7.1 开启训练

超参数设定如下:

  • BATCH_SIZE = 16
  • EPOCH_NUM = 20
  • learning_rate=0.0002 损失函数:
  • kl_loss
In [33]
import paddle.nn.functional as Fimport paddle

y_preds = []
labels_list = []
BATCH_SIZE = 16train_data = x_train
train_data_y = y_train
test_data = x_test
test_data_y = y_test
compute_kl_loss = kl_loss()
CET_loss = paddle.nn.CrossEntropyLoss()def train(model):
    print('start training ... ')    # 开启模型训练模式
    model.train()
    EPOCH_NUM = 20
    train_num = 0
    scheduler = paddle.optimizer.lr.CosineAnnealingDecay(learning_rate=0.0002, T_max=int(train_data.shape[0]/BATCH_SIZE*EPOCH_NUM), verbose=False)
    optimizer = paddle.optimizer.Adam(learning_rate=scheduler, parameters=model.parameters())    for epoch_id in range(EPOCH_NUM):        # 在每轮迭代开始之前,将训练数据的顺序随机的打乱
        np.random.shuffle(train_data)        # 将训练数据进行拆分,每个batch包含8条数据
        mini_batches = [np.append(train_data[k: k+BATCH_SIZE], train_data_y[k: k+BATCH_SIZE], axis = 1) for k in range(0, len(train_data), BATCH_SIZE)]        for batch_id, data in enumerate(mini_batches):
            features_np = np.array(data[:, :8], np.float32)
            labels_np = np.array(data[:, -1:], np.float32)

            features = paddle.to_tensor(features_np)
            labels = paddle.to_tensor(labels_np)            #前向计算
            #y_pred = model(features)
            y_pred1 = model(features)
            y_pred2 = model(features)
            cost = compute_kl_loss(y_pred1, y_pred2, label=labels)            # cost = CET_loss(y_pred, labels)
            #cost = F.mse_loss(y_pred, label=labels)
            train_cost = cost.numpy()[0]            #反向传播
            cost.backward()            #最小化loss,更新参数
            optimizer.step()            # 清除梯度
            optimizer.clear_grad()            if batch_id % 500 == 0 and epoch_id % 1 == 0:                print("Pass:%d,Cost:%0.5f"%(epoch_id, train_cost))

            train_num = train_num + BATCH_SIZE
            train_nums.append(train_num)
            train_costs.append(train_cost)

model = Classification()
train(model)
登录后复制

start training ...
Pass:0,Cost:2.43391
Pass:1,Cost:3.92359
Pass:2,Cost:2.98257
Pass:3,Cost:2.93184
Pass:4,Cost:2.18770
Pass:5,Cost:3.19956
Pass:6,Cost:4.07202
Pass:7,Cost:2.55369
Pass:8,Cost:3.19636
Pass:9,Cost:3.43391
Pass:10,Cost:2.27505
Pass:11,Cost:1.95374
Pass:12,Cost:2.40070
Pass:13,Cost:3.80006
Pass:14,Cost:2.00660
Pass:15,Cost:3.59392
Pass:16,Cost:2.63512
Pass:17,Cost:2.65104
Pass:18,Cost:2.91626
Pass:19,Cost:2.96661
登录后复制


7.2 训练过程可视化

In [41]
import matplotlibimport matplotlib.pyplot as pltimport warnings
warnings.filterwarnings('ignore')
%matplotlib inline

draw_train_process(train_nums, train_costs)
登录后复制

<Figure size 640x480 with 1 Axes>
登录后复制


8. 模型预测

  • 使用测试集数据进行预测
  • 对预测后的数据进行形状转换方便后续可视化
In [36]
train_data = x_train
train_data_y = y_train
test_data = x_test
test_data_y = y_testdef predict(model):
    print('start evaluating ... ')
    model.eval()
    outputs = []
    mini_batches = [np.append(test_data[k: k+BATCH_SIZE], test_data_y[k: k+BATCH_SIZE], axis = 1) for k in range(0, len(test_data), BATCH_SIZE)]    for data in mini_batches:
        features_np = np.array(data[:, :8], np.float32)
        features = paddle.to_tensor(features_np)
        pred = model(features)
        out = paddle.argmax(pred, axis=1)
        outputs.extend(out.numpy())    return outputs

outputs = predict(model)
登录后复制

start evaluating ...
登录后复制

In [38]
predict_result = []for infer_feature in test_data:
    infer_feature = infer_feature.reshape(1, 8)
    infer_feature = paddle.to_tensor(np.array(infer_feature, dtype='float32'))
    result = model(infer_feature)
    predict_result.append(result)print(predict_result)
登录后复制

[Tensor(shape=[1, 1], dtype=float32, place=Place(gpu:0), stop_gradient=False,
       [[0.06025434]]), Tensor(shape=[1, 1], dtype=float32, place=Place(gpu:0), stop_gradient=False,
       [[0.26668236]]), Tensor(shape=[1, 1], dtype=float32, place=Place(gpu:0), stop_gradient=False,
       [[0.04699296]]), Tensor(shape=[1, 1], dtype=float32, place=Place(gpu:0), stop_gradient=False,
       [[0.15396497]]), Tensor(shape=[1, 1], dtype=float32, place=Place(gpu:0), stop_gradient=False,
       [[0.11334734]]), Tensor(shape=[1, 1], dtype=float32, place=Place(gpu:0), stop_gradient=False,
       [[0.22626641]]), Tensor(shape=[1, 1], dtype=float32, place=Place(gpu:0), stop_gradient=False,
       [[-0.02553241]]), Tensor(shape=[1, 1], dtype=float32, place=Place(gpu:0), stop_gradient=False,
       [[0.00950530]]), Tensor(shape=[1, 1], dtype=float32, place=Place(gpu:0), stop_gradient=False,
       [[0.56165761]]), Tensor(shape=[1, 1], dtype=float32, place=Place(gpu:0), stop_gradient=False,
       [[0.33237797]]), Tensor(shape=[1, 1], dtype=float32, place=Place(gpu:0), stop_gradient=False,
       [[0.16205853]]), Tensor(shape=[1, 1], dtype=float32, place=Place(gpu:0), stop_gradient=False,
       [[0.44974920]]), Tensor(shape=[1, 1], dtype=float32, place=Place(gpu:0), stop_gradient=False,
       [[-0.11122769]]), Tensor(shape=[1, 1], dtype=float32, place=Place(gpu:0), stop_gradient=False,
       [[-0.78721941]]), Tensor(shape=[1, 1], dtype=float32, place=Place(gpu:0), stop_gradient=False,
       [[0.29552042]]), Tensor(shape=[1, 1], dtype=float32, place=Place(gpu:0), stop_gradient=False,
       [[0.05363976]]), Tensor(shape=[1, 1], dtype=float32, place=Place(gpu:0), stop_gradient=False,
       [[0.34395823]]), Tensor(shape=[1, 1], dtype=float32, place=Place(gpu:0), stop_gradient=False,
       [[-0.02476013]]), Tensor(shape=[1, 1], dtype=float32, place=Place(gpu:0), stop_gradient=False,
       [[0.24630979]]), Tensor(shape=[1, 1], dtype=float32, place=Place(gpu:0), stop_gradient=False,
       [[-0.41399071]]), Tensor(shape=[1, 1], dtype=float32, place=Place(gpu:0), stop_gradient=False,
       [[0.09647968]]), Tensor(shape=[1, 1], dtype=float32, place=Place(gpu:0), stop_gradient=False,
       [[0.25168726]]), Tensor(shape=[1, 1], dtype=float32, place=Place(gpu:0), stop_gradient=False,
       [[0.12463144]]), Tensor(shape=[1, 1], dtype=float32, place=Place(gpu:0), stop_gradient=False,
       [[-0.17930359]]), Tensor(shape=[1, 1], dtype=float32, place=Place(gpu:0), stop_gradient=False,
       [[0.22265507]]), Tensor(shape=[1, 1], dtype=float32, place=Place(gpu:0), stop_gradient=False,
       [[0.19350600]]), Tensor(shape=[1, 1], dtype=float32, place=Place(gpu:0), stop_gradient=False,
       [[0.16149586]]), Tensor(shape=[1, 1], dtype=float32, place=Place(gpu:0), stop_gradient=False,
       [[0.97867000]]), Tensor(shape=[1, 1], dtype=float32, place=Place(gpu:0), stop_gradient=False,
       [[-0.14237657]]), Tensor(shape=[1, 1], dtype=float32, place=Place(gpu:0), stop_gradient=False,
       [[0.19865277]]), Tensor(shape=[1, 1], dtype=float32, place=Place(gpu:0), stop_gradient=False,
       [[0.06837564]]), Tensor(shape=[1, 1], dtype=float32, place=Place(gpu:0), stop_gradient=False,
       [[-0.33876964]]), Tensor(shape=[1, 1], dtype=float32, place=Place(gpu:0), stop_gradient=False,
       [[0.08810827]]), Tensor(shape=[1, 1], dtype=float32, place=Place(gpu:0), stop_gradient=False,
       [[-1.31689727]]), Tensor(shape=[1, 1], dtype=float32, place=Place(gpu:0), stop_gradient=False,
       [[0.25119871]]), Tensor(shape=[1, 1], dtype=float32, place=Place(gpu:0), stop_gradient=False,
       [[-0.33098105]]), Tensor(shape=[1, 1], dtype=float32, place=Place(gpu:0), stop_gradient=False,
       [[-0.15266529]]), Tensor(shape=[1, 1], dtype=float32, place=Place(gpu:0), stop_gradient=False,
       [[-0.05445822]]), Tensor(shape=[1, 1], dtype=float32, place=Place(gpu:0), stop_gradient=False,
       [[0.00509700]]), Tensor(shape=[1, 1], dtype=float32, place=Place(gpu:0), stop_gradient=False,
       [[0.18745518]]), Tensor(shape=[1, 1], dtype=float32, place=Place(gpu:0), stop_gradient=False,
       [[0.07550180]]), Tensor(shape=[1, 1], dtype=float32, place=Place(gpu:0), stop_gradient=False,
       [[0.26571921]]), Tensor(shape=[1, 1], dtype=float32, place=Place(gpu:0), stop_gradient=False,
       [[0.34217680]]), Tensor(shape=[1, 1], dtype=float32, place=Place(gpu:0), stop_gradient=False,
       [[0.08926390]]), Tensor(shape=[1, 1], dtype=float32, place=Place(gpu:0), stop_gradient=False,
       [[-0.30792972]]), Tensor(shape=[1, 1], dtype=float32, place=Place(gpu:0), stop_gradient=False,
       [[0.16032460]]), Tensor(shape=[1, 1], dtype=float32, place=Place(gpu:0), stop_gradient=False,
       [[0.57145494]]), Tensor(shape=[1, 1], dtype=float32, place=Place(gpu:0), stop_gradient=False,
       [[0.54297256]]), Tensor(shape=[1, 1], dtype=float32, place=Place(gpu:0), stop_gradient=False,
       [[0.25611365]]), Tensor(shape=[1, 1], dtype=float32, place=Place(gpu:0), stop_gradient=False,
       [[0.63418227]]), Tensor(shape=[1, 1], dtype=float32, place=Place(gpu:0), stop_gradient=False,
       [[0.00557299]]), Tensor(shape=[1, 1], dtype=float32, place=Place(gpu:0), stop_gradient=False,
       [[0.18981141]]), Tensor(shape=[1, 1], dtype=float32, place=Place(gpu:0), stop_gradient=False,
       [[-0.12302241]]), Tensor(shape=[1, 1], dtype=float32, place=Place(gpu:0), stop_gradient=False,
       [[0.03510806]]), Tensor(shape=[1, 1], dtype=float32, place=Place(gpu:0), stop_gradient=False,
       [[0.04525859]]), Tensor(shape=[1, 1], dtype=float32, place=Place(gpu:0), stop_gradient=False,
       [[0.00092174]]), Tensor(shape=[1, 1], dtype=float32, place=Place(gpu:0), stop_gradient=False,
       [[-0.13034135]]), Tensor(shape=[1, 1], dtype=float32, place=Place(gpu:0), stop_gradient=False,
       [[-0.18077031]]), Tensor(shape=[1, 1], dtype=float32, place=Place(gpu:0), stop_gradient=False,
       [[0.16647439]]), Tensor(shape=[1, 1], dtype=float32, place=Place(gpu:0), stop_gradient=False,
       [[0.68720388]]), Tensor(shape=[1, 1], dtype=float32, place=Place(gpu:0), stop_gradient=False,
       [[-0.44611922]]), Tensor(shape=[1, 1], dtype=float32, place=Place(gpu:0), stop_gradient=False,
       [[-0.04261202]]), Tensor(shape=[1, 1], dtype=float32, place=Place(gpu:0), stop_gradient=False,
       [[0.09249763]]), Tensor(shape=[1, 1], dtype=float32, place=Place(gpu:0), stop_gradient=False,
       [[0.58799160]]), Tensor(shape=[1, 1], dtype=float32, place=Place(gpu:0), stop_gradient=False,
       [[0.79527473]]), Tensor(shape=[1, 1], dtype=float32, place=Place(gpu:0), stop_gradient=False,
       [[0.96323133]]), Tensor(shape=[1, 1], dtype=float32, place=Place(gpu:0), stop_gradient=False,
       [[-0.35711923]]), Tensor(shape=[1, 1], dtype=float32, place=Place(gpu:0), stop_gradient=False,
       [[-0.18494114]]), Tensor(shape=[1, 1], dtype=float32, place=Place(gpu:0), stop_gradient=False,
       [[-0.07933167]]), Tensor(shape=[1, 1], dtype=float32, place=Place(gpu:0), stop_gradient=False,
       [[0.13546264]]), Tensor(shape=[1, 1], dtype=float32, place=Place(gpu:0), stop_gradient=False,
       [[-0.02684295]]), Tensor(shape=[1, 1], dtype=float32, place=Place(gpu:0), stop_gradient=False,
       [[0.75451505]]), Tensor(shape=[1, 1], dtype=float32, place=Place(gpu:0), stop_gradient=False,
       [[-0.11692813]]), Tensor(shape=[1, 1], dtype=float32, place=Place(gpu:0), stop_gradient=False,
       [[-0.14113143]]), Tensor(shape=[1, 1], dtype=float32, place=Place(gpu:0), stop_gradient=False,
       [[0.33698213]]), Tensor(shape=[1, 1], dtype=float32, place=Place(gpu:0), stop_gradient=False,
       [[0.38676432]]), Tensor(shape=[1, 1], dtype=float32, place=Place(gpu:0), stop_gradient=False,
       [[-0.03340812]]), Tensor(shape=[1, 1], dtype=float32, place=Place(gpu:0), stop_gradient=False,
       [[0.22545892]]), Tensor(shape=[1, 1], dtype=float32, place=Place(gpu:0), stop_gradient=False,
       [[0.21347922]]), Tensor(shape=[1, 1], dtype=float32, place=Place(gpu:0), stop_gradient=False,
       [[-0.14782789]]), Tensor(shape=[1, 1], dtype=float32, place=Place(gpu:0), stop_gradient=False,
       [[0.00954092]]), Tensor(shape=[1, 1], dtype=float32, place=Place(gpu:0), stop_gradient=False,
       [[1.06012034]]), Tensor(shape=[1, 1], dtype=float32, place=Place(gpu:0), stop_gradient=False,
       [[-0.22003201]]), Tensor(shape=[1, 1], dtype=float32, place=Place(gpu:0), stop_gradient=False,
       [[0.70404851]]), Tensor(shape=[1, 1], dtype=float32, place=Place(gpu:0), stop_gradient=False,
       [[0.02809775]]), Tensor(shape=[1, 1], dtype=float32, place=Place(gpu:0), stop_gradient=False,
       [[-0.16613525]]), Tensor(shape=[1, 1], dtype=float32, place=Place(gpu:0), stop_gradient=False,
       [[0.06436903]]), Tensor(shape=[1, 1], dtype=float32, place=Place(gpu:0), stop_gradient=False,
       [[0.05216470]]), Tensor(shape=[1, 1], dtype=float32, place=Place(gpu:0), stop_gradient=False,
       [[0.50551772]]), Tensor(shape=[1, 1], dtype=float32, place=Place(gpu:0), stop_gradient=False,
       [[0.35137683]]), Tensor(shape=[1, 1], dtype=float32, place=Place(gpu:0), stop_gradient=False,
       [[-0.15199861]]), Tensor(shape=[1, 1], dtype=float32, place=Place(gpu:0), stop_gradient=False,
       [[-0.27733982]]), Tensor(shape=[1, 1], dtype=float32, place=Place(gpu:0), stop_gradient=False,
       [[-0.05591117]]), Tensor(shape=[1, 1], dtype=float32, place=Place(gpu:0), stop_gradient=False,
       [[0.43492565]]), Tensor(shape=[1, 1], dtype=float32, place=Place(gpu:0), stop_gradient=False,
       [[0.09615488]]), Tensor(shape=[1, 1], dtype=float32, place=Place(gpu:0), stop_gradient=False,
       [[-0.32641587]]), Tensor(shape=[1, 1], dtype=float32, place=Place(gpu:0), stop_gradient=False,
       [[0.04105541]]), Tensor(shape=[1, 1], dtype=float32, place=Place(gpu:0), stop_gradient=False,
       [[0.16224015]]), Tensor(shape=[1, 1], dtype=float32, place=Place(gpu:0), stop_gradient=False,
       [[-1.01362646]]), Tensor(shape=[1, 1], dtype=float32, place=Place(gpu:0), stop_gradient=False,
       [[-0.23819336]]), Tensor(shape=[1, 1], dtype=float32, place=Place(gpu:0), stop_gradient=False,
       [[0.46461323]]), Tensor(shape=[1, 1], dtype=float32, place=Place(gpu:0), stop_gradient=False,
       [[0.37720412]]), Tensor(shape=[1, 1], dtype=float32, place=Place(gpu:0), stop_gradient=False,
       [[0.03798632]]), Tensor(shape=[1, 1], dtype=float32, place=Place(gpu:0), stop_gradient=False,
       [[0.65613806]]), Tensor(shape=[1, 1], dtype=float32, place=Place(gpu:0), stop_gradient=False,
       [[-0.23755836]]), Tensor(shape=[1, 1], dtype=float32, place=Place(gpu:0), stop_gradient=False,
       [[0.69738317]]), Tensor(shape=[1, 1], dtype=float32, place=Place(gpu:0), stop_gradient=False,
       [[0.25705069]]), Tensor(shape=[1, 1], dtype=float32, place=Place(gpu:0), stop_gradient=False,
       [[-1.40520060]]), Tensor(shape=[1, 1], dtype=float32, place=Place(gpu:0), stop_gradient=False,
       [[0.21922657]]), Tensor(shape=[1, 1], dtype=float32, place=Place(gpu:0), stop_gradient=False,
       [[0.02883075]]), Tensor(shape=[1, 1], dtype=float32, place=Place(gpu:0), stop_gradient=False,
       [[0.48285359]]), Tensor(shape=[1, 1], dtype=float32, place=Place(gpu:0), stop_gradient=False,
       [[0.23328757]]), Tensor(shape=[1, 1], dtype=float32, place=Place(gpu:0), stop_gradient=False,
       [[-1.09615302]]), Tensor(shape=[1, 1], dtype=float32, place=Place(gpu:0), stop_gradient=False,
       [[-0.21412531]]), Tensor(shape=[1, 1], dtype=float32, place=Place(gpu:0), stop_gradient=False,
       [[-0.00535169]]), Tensor(shape=[1, 1], dtype=float32, place=Place(gpu:0), stop_gradient=False,
       [[0.79399991]]), Tensor(shape=[1, 1], dtype=float32, place=Place(gpu:0), stop_gradient=False,
       [[0.52258801]]), Tensor(shape=[1, 1], dtype=float32, place=Place(gpu:0), stop_gradient=False,
       [[0.29668379]]), Tensor(shape=[1, 1], dtype=float32, place=Place(gpu:0), stop_gradient=False,
       [[-0.30907032]]), Tensor(shape=[1, 1], dtype=float32, place=Place(gpu:0), stop_gradient=False,
       [[-0.55264854]]), Tensor(shape=[1, 1], dtype=float32, place=Place(gpu:0), stop_gradient=False,
       [[0.66549766]]), Tensor(shape=[1, 1], dtype=float32, place=Place(gpu:0), stop_gradient=False,
       [[0.56879592]]), Tensor(shape=[1, 1], dtype=float32, place=Place(gpu:0), stop_gradient=False,
       [[0.47440132]]), Tensor(shape=[1, 1], dtype=float32, place=Place(gpu:0), stop_gradient=False,
       [[-0.02180216]]), Tensor(shape=[1, 1], dtype=float32, place=Place(gpu:0), stop_gradient=False,
       [[0.09484225]]), Tensor(shape=[1, 1], dtype=float32, place=Place(gpu:0), stop_gradient=False,
       [[0.03586899]]), Tensor(shape=[1, 1], dtype=float32, place=Place(gpu:0), stop_gradient=False,
       [[0.47702056]]), Tensor(shape=[1, 1], dtype=float32, place=Place(gpu:0), stop_gradient=False,
       [[-0.11216781]]), Tensor(shape=[1, 1], dtype=float32, place=Place(gpu:0), stop_gradient=False,
       [[-0.10515133]]), Tensor(shape=[1, 1], dtype=float32, place=Place(gpu:0), stop_gradient=False,
       [[0.60479486]]), Tensor(shape=[1, 1], dtype=float32, place=Place(gpu:0), stop_gradient=False,
       [[0.32108724]]), Tensor(shape=[1, 1], dtype=float32, place=Place(gpu:0), stop_gradient=False,
       [[0.07980973]]), Tensor(shape=[1, 1], dtype=float32, place=Place(gpu:0), stop_gradient=False,
       [[-0.04501529]]), Tensor(shape=[1, 1], dtype=float32, place=Place(gpu:0), stop_gradient=False,
       [[0.38887209]]), Tensor(shape=[1, 1], dtype=float32, place=Place(gpu:0), stop_gradient=False,
       [[0.26931447]]), Tensor(shape=[1, 1], dtype=float32, place=Place(gpu:0), stop_gradient=False,
       [[0.10054627]]), Tensor(shape=[1, 1], dtype=float32, place=Place(gpu:0), stop_gradient=False,
       [[-0.22147605]]), Tensor(shape=[1, 1], dtype=float32, place=Place(gpu:0), stop_gradient=False,
       [[-0.06280908]]), Tensor(shape=[1, 1], dtype=float32, place=Place(gpu:0), stop_gradient=False,
       [[-0.01246339]]), Tensor(shape=[1, 1], dtype=float32, place=Place(gpu:0), stop_gradient=False,
       [[-0.14042327]]), Tensor(shape=[1, 1], dtype=float32, place=Place(gpu:0), stop_gradient=False,
       [[-0.38733354]]), Tensor(shape=[1, 1], dtype=float32, place=Place(gpu:0), stop_gradient=False,
       [[0.03984775]]), Tensor(shape=[1, 1], dtype=float32, place=Place(gpu:0), stop_gradient=False,
       [[-0.40873846]]), Tensor(shape=[1, 1], dtype=float32, place=Place(gpu:0), stop_gradient=False,
       [[0.37586206]]), Tensor(shape=[1, 1], dtype=float32, place=Place(gpu:0), stop_gradient=False,
       [[0.20004481]]), Tensor(shape=[1, 1], dtype=float32, place=Place(gpu:0), stop_gradient=False,
       [[-0.50934064]]), Tensor(shape=[1, 1], dtype=float32, place=Place(gpu:0), stop_gradient=False,
       [[0.18784773]]), Tensor(shape=[1, 1], dtype=float32, place=Place(gpu:0), stop_gradient=False,
       [[0.14203307]]), Tensor(shape=[1, 1], dtype=float32, place=Place(gpu:0), stop_gradient=False,
       [[0.07040142]]), Tensor(shape=[1, 1], dtype=float32, place=Place(gpu:0), stop_gradient=False,
       [[-0.54865539]]), Tensor(shape=[1, 1], dtype=float32, place=Place(gpu:0), stop_gradient=False,
       [[0.55391824]]), Tensor(shape=[1, 1], dtype=float32, place=Place(gpu:0), stop_gradient=False,
       [[0.38516435]]), Tensor(shape=[1, 1], dtype=float32, place=Place(gpu:0), stop_gradient=False,
       [[-0.02930367]]), Tensor(shape=[1, 1], dtype=float32, place=Place(gpu:0), stop_gradient=False,
       [[-0.02538344]]), Tensor(shape=[1, 1], dtype=float32, place=Place(gpu:0), stop_gradient=False,
       [[-0.39730838]]), Tensor(shape=[1, 1], dtype=float32, place=Place(gpu:0), stop_gradient=False,
       [[0.01709569]]), Tensor(shape=[1, 1], dtype=float32, place=Place(gpu:0), stop_gradient=False,
       [[-0.03152084]]), Tensor(shape=[1, 1], dtype=float32, place=Place(gpu:0), stop_gradient=False,
       [[-0.12164506]]), Tensor(shape=[1, 1], dtype=float32, place=Place(gpu:0), stop_gradient=False,
       [[-0.26876831]]), Tensor(shape=[1, 1], dtype=float32, place=Place(gpu:0), stop_gradient=False,
       [[0.67705190]]), Tensor(shape=[1, 1], dtype=float32, place=Place(gpu:0), stop_gradient=False,
       [[0.13091573]]), Tensor(shape=[1, 1], dtype=float32, place=Place(gpu:0), stop_gradient=False,
       [[0.02252182]]), Tensor(shape=[1, 1], dtype=float32, place=Place(gpu:0), stop_gradient=False,
       [[-0.28376839]]), Tensor(shape=[1, 1], dtype=float32, place=Place(gpu:0), stop_gradient=False,
       [[0.23220628]]), Tensor(shape=[1, 1], dtype=float32, place=Place(gpu:0), stop_gradient=False,
       [[-0.19528371]]), Tensor(shape=[1, 1], dtype=float32, place=Place(gpu:0), stop_gradient=False,
       [[-0.00430268]]), Tensor(shape=[1, 1], dtype=float32, place=Place(gpu:0), stop_gradient=False,
       [[0.85965836]]), Tensor(shape=[1, 1], dtype=float32, place=Place(gpu:0), stop_gradient=False,
       [[-0.09281531]]), Tensor(shape=[1, 1], dtype=float32, place=Place(gpu:0), stop_gradient=False,
       [[0.71069968]]), Tensor(shape=[1, 1], dtype=float32, place=Place(gpu:0), stop_gradient=False,
       [[-0.17499715]]), Tensor(shape=[1, 1], dtype=float32, place=Place(gpu:0), stop_gradient=False,
       [[0.19014531]]), Tensor(shape=[1, 1], dtype=float32, place=Place(gpu:0), stop_gradient=False,
       [[-0.73743546]]), Tensor(shape=[1, 1], dtype=float32, place=Place(gpu:0), stop_gradient=False,
       [[-0.19340679]]), Tensor(shape=[1, 1], dtype=float32, place=Place(gpu:0), stop_gradient=False,
       [[0.31273481]]), Tensor(shape=[1, 1], dtype=float32, place=Place(gpu:0), stop_gradient=False,
       [[0.09856954]]), Tensor(shape=[1, 1], dtype=float32, place=Place(gpu:0), stop_gradient=False,
       [[0.03048946]]), Tensor(shape=[1, 1], dtype=float32, place=Place(gpu:0), stop_gradient=False,
       [[0.24947995]]), Tensor(shape=[1, 1], dtype=float32, place=Place(gpu:0), stop_gradient=False,
       [[0.11751899]]), Tensor(shape=[1, 1], dtype=float32, place=Place(gpu:0), stop_gradient=False,
       [[-0.24697509]]), Tensor(shape=[1, 1], dtype=float32, place=Place(gpu:0), stop_gradient=False,
       [[0.17461219]]), Tensor(shape=[1, 1], dtype=float32, place=Place(gpu:0), stop_gradient=False,
       [[0.41916654]]), Tensor(shape=[1, 1], dtype=float32, place=Place(gpu:0), stop_gradient=False,
       [[0.37340474]]), Tensor(shape=[1, 1], dtype=float32, place=Place(gpu:0), stop_gradient=False,
       [[0.25891006]]), Tensor(shape=[1, 1], dtype=float32, place=Place(gpu:0), stop_gradient=False,
       [[0.37807691]]), Tensor(shape=[1, 1], dtype=float32, place=Place(gpu:0), stop_gradient=False,
       [[1.02975428]]), Tensor(shape=[1, 1], dtype=float32, place=Place(gpu:0), stop_gradient=False,
       [[-0.10468236]]), Tensor(shape=[1, 1], dtype=float32, place=Place(gpu:0), stop_gradient=False,
       [[0.53602326]]), Tensor(shape=[1, 1], dtype=float32, place=Place(gpu:0), stop_gradient=False,
       [[0.55852354]]), Tensor(shape=[1, 1], dtype=float32, place=Place(gpu:0), stop_gradient=False,
       [[-0.21298340]]), Tensor(shape=[1, 1], dtype=float32, place=Place(gpu:0), stop_gradient=False,
       [[0.09785891]]), Tensor(shape=[1, 1], dtype=float32, place=Place(gpu:0), stop_gradient=False,
       [[0.21151096]]), Tensor(shape=[1, 1], dtype=float32, place=Place(gpu:0), stop_gradient=False,
       [[-0.04951549]]), Tensor(shape=[1, 1], dtype=float32, place=Place(gpu:0), stop_gradient=False,
       [[0.80943894]]), Tensor(shape=[1, 1], dtype=float32, place=Place(gpu:0), stop_gradient=False,
       [[-0.04852328]]), Tensor(shape=[1, 1], dtype=float32, place=Place(gpu:0), stop_gradient=False,
       [[-0.15818748]]), Tensor(shape=[1, 1], dtype=float32, place=Place(gpu:0), stop_gradient=False,
       [[0.34501284]]), Tensor(shape=[1, 1], dtype=float32, place=Place(gpu:0), stop_gradient=False,
       [[-0.21866712]]), Tensor(shape=[1, 1], dtype=float32, place=Place(gpu:0), stop_gradient=False,
       [[-0.17124262]]), Tensor(shape=[1, 1], dtype=float32, place=Place(gpu:0), stop_gradient=False,
       [[-0.12341249]]), Tensor(shape=[1, 1], dtype=float32, place=Place(gpu:0), stop_gradient=False,
       [[0.34145629]]), Tensor(shape=[1, 1], dtype=float32, place=Place(gpu:0), stop_gradient=False,
       [[0.23096427]]), Tensor(shape=[1, 1], dtype=float32, place=Place(gpu:0), stop_gradient=False,
       [[-0.11948290]]), Tensor(shape=[1, 1], dtype=float32, place=Place(gpu:0), stop_gradient=False,
       [[0.44626537]]), Tensor(shape=[1, 1], dtype=float32, place=Place(gpu:0), stop_gradient=False,
       [[-0.13348910]]), Tensor(shape=[1, 1], dtype=float32, place=Place(gpu:0), stop_gradient=False,
       [[0.33801559]]), Tensor(shape=[1, 1], dtype=float32, place=Place(gpu:0), stop_gradient=False,
       [[0.15752676]]), Tensor(shape=[1, 1], dtype=float32, place=Place(gpu:0), stop_gradient=False,
       [[0.57183367]]), Tensor(shape=[1, 1], dtype=float32, place=Place(gpu:0), stop_gradient=False,
       [[-0.12696415]]), Tensor(shape=[1, 1], dtype=float32, place=Place(gpu:0), stop_gradient=False,
       [[0.73151672]]), Tensor(shape=[1, 1], dtype=float32, place=Place(gpu:0), stop_gradient=False,
       [[0.04441139]]), Tensor(shape=[1, 1], dtype=float32, place=Place(gpu:0), stop_gradient=False,
       [[0.33734927]]), Tensor(shape=[1, 1], dtype=float32, place=Place(gpu:0), stop_gradient=False,
       [[-0.12257078]]), Tensor(shape=[1, 1], dtype=float32, place=Place(gpu:0), stop_gradient=False,
       [[0.42197654]]), Tensor(shape=[1, 1], dtype=float32, place=Place(gpu:0), stop_gradient=False,
       [[0.07283434]]), Tensor(shape=[1, 1], dtype=float32, place=Place(gpu:0), stop_gradient=False,
       [[0.12016518]]), Tensor(shape=[1, 1], dtype=float32, place=Place(gpu:0), stop_gradient=False,
       [[-0.22773159]]), Tensor(shape=[1, 1], dtype=float32, place=Place(gpu:0), stop_gradient=False,
       [[-0.00632009]]), Tensor(shape=[1, 1], dtype=float32, place=Place(gpu:0), stop_gradient=False,
       [[0.58992362]]), Tensor(shape=[1, 1], dtype=float32, place=Place(gpu:0), stop_gradient=False,
       [[0.33788848]]), Tensor(shape=[1, 1], dtype=float32, place=Place(gpu:0), stop_gradient=False,
       [[-0.22251603]]), Tensor(shape=[1, 1], dtype=float32, place=Place(gpu:0), stop_gradient=False,
       [[0.36759052]]), Tensor(shape=[1, 1], dtype=float32, place=Place(gpu:0), stop_gradient=False,
       [[-0.01202503]]), Tensor(shape=[1, 1], dtype=float32, place=Place(gpu:0), stop_gradient=False,
       [[0.19001615]]), Tensor(shape=[1, 1], dtype=float32, place=Place(gpu:0), stop_gradient=False,
       [[0.16210946]]), Tensor(shape=[1, 1], dtype=float32, place=Place(gpu:0), stop_gradient=False,
       [[0.07992619]]), Tensor(shape=[1, 1], dtype=float32, place=Place(gpu:0), stop_gradient=False,
       [[0.00859043]]), Tensor(shape=[1, 1], dtype=float32, place=Place(gpu:0), stop_gradient=False,
       [[0.93312132]]), Tensor(shape=[1, 1], dtype=float32, place=Place(gpu:0), stop_gradient=False,
       [[0.34916848]]), Tensor(shape=[1, 1], dtype=float32, place=Place(gpu:0), stop_gradient=False,
       [[0.43634501]]), Tensor(shape=[1, 1], dtype=float32, place=Place(gpu:0), stop_gradient=False,
       [[-0.67739213]]), Tensor(shape=[1, 1], dtype=float32, place=Place(gpu:0), stop_gradient=False,
       [[-0.02566296]]), Tensor(shape=[1, 1], dtype=float32, place=Place(gpu:0), stop_gradient=False,
       [[0.25677067]]), Tensor(shape=[1, 1], dtype=float32, place=Place(gpu:0), stop_gradient=False,
       [[0.20933753]]), Tensor(shape=[1, 1], dtype=float32, place=Place(gpu:0), stop_gradient=False,
       [[0.06095613]]), Tensor(shape=[1, 1], dtype=float32, place=Place(gpu:0), stop_gradient=False,
       [[0.49417597]]), Tensor(shape=[1, 1], dtype=float32, place=Place(gpu:0), stop_gradient=False,
       [[-0.04814164]]), Tensor(shape=[1, 1], dtype=float32, place=Place(gpu:0), stop_gradient=False,
       [[0.47177973]]), Tensor(shape=[1, 1], dtype=float32, place=Place(gpu:0), stop_gradient=False,
       [[-0.34180573]]), Tensor(shape=[1, 1], dtype=float32, place=Place(gpu:0), stop_gradient=False,
       [[0.21158339]]), Tensor(shape=[1, 1], dtype=float32, place=Place(gpu:0), stop_gradient=False,
       [[0.06199323]]), Tensor(shape=[1, 1], dtype=float32, place=Place(gpu:0), stop_gradient=False,
       [[-0.17558643]]), Tensor(shape=[1, 1], dtype=float32, place=Place(gpu:0), stop_gradient=False,
       [[0.15741932]]), Tensor(shape=[1, 1], dtype=float32, place=Place(gpu:0), stop_gradient=False,
       [[-0.19417530]]), Tensor(shape=[1, 1], dtype=float32, place=Place(gpu:0), stop_gradient=False,
       [[0.46489933]]), Tensor(shape=[1, 1], dtype=float32, place=Place(gpu:0), stop_gradient=False,
       [[-0.53986490]]), Tensor(shape=[1, 1], dtype=float32, place=Place(gpu:0), stop_gradient=False,
       [[0.52108425]]), Tensor(shape=[1, 1], dtype=float32, place=Place(gpu:0), stop_gradient=False,
       [[-0.32266229]]), Tensor(shape=[1, 1], dtype=float32, place=Place(gpu:0), stop_gradient=False,
       [[-0.23374096]]), Tensor(shape=[1, 1], dtype=float32, place=Place(gpu:0), stop_gradient=False,
       [[0.16298553]]), Tensor(shape=[1, 1], dtype=float32, place=Place(gpu:0), stop_gradient=False,
       [[-0.22927698]]), Tensor(shape=[1, 1], dtype=float32, place=Place(gpu:0), stop_gradient=False,
       [[0.16080782]]), Tensor(shape=[1, 1], dtype=float32, place=Place(gpu:0), stop_gradient=False,
       [[0.20695420]]), Tensor(shape=[1, 1], dtype=float32, place=Place(gpu:0), stop_gradient=False,
       [[-0.59630513]]), Tensor(shape=[1, 1], dtype=float32, place=Place(gpu:0), stop_gradient=False,
       [[1.07300067]]), Tensor(shape=[1, 1], dtype=float32, place=Place(gpu:0), stop_gradient=False,
       [[0.79350090]]), Tensor(shape=[1, 1], dtype=float32, place=Place(gpu:0), stop_gradient=False,
       [[0.41532162]]), Tensor(shape=[1, 1], dtype=float32, place=Place(gpu:0), stop_gradient=False,
       [[0.26769426]]), Tensor(shape=[1, 1], dtype=float32, place=Place(gpu:0), stop_gradient=False,
       [[0.36136031]]), Tensor(shape=[1, 1], dtype=float32, place=Place(gpu:0), stop_gradient=False,
       [[0.45680836]]), Tensor(shape=[1, 1], dtype=float32, place=Place(gpu:0), stop_gradient=False,
       [[0.38632005]]), Tensor(shape=[1, 1], dtype=float32, place=Place(gpu:0), stop_gradient=False,
       [[-0.13972732]]), Tensor(shape=[1, 1], dtype=float32, place=Place(gpu:0), stop_gradient=False,
       [[-0.34614977]]), Tensor(shape=[1, 1], dtype=float32, place=Place(gpu:0), stop_gradient=False,
       [[-0.13971359]]), Tensor(shape=[1, 1], dtype=float32, place=Place(gpu:0), stop_gradient=False,
       [[0.16951732]]), Tensor(shape=[1, 1], dtype=float32, place=Place(gpu:0), stop_gradient=False,
       [[-0.03548551]]), Tensor(shape=[1, 1], dtype=float32, place=Place(gpu:0), stop_gradient=False,
       [[-0.04101467]]), Tensor(shape=[1, 1], dtype=float32, place=Place(gpu:0), stop_gradient=False,
       [[-0.09060603]]), Tensor(shape=[1, 1], dtype=float32, place=Place(gpu:0), stop_gradient=False,
       [[-0.11193165]]), Tensor(shape=[1, 1], dtype=float32, place=Place(gpu:0), stop_gradient=False,
       [[0.11157656]]), Tensor(shape=[1, 1], dtype=float32, place=Place(gpu:0), stop_gradient=False,
       [[0.16849741]]), Tensor(shape=[1, 1], dtype=float32, place=Place(gpu:0), stop_gradient=False,
       [[0.24559656]]), Tensor(shape=[1, 1], dtype=float32, place=Place(gpu:0), stop_gradient=False,
       [[-0.24626759]]), Tensor(shape=[1, 1], dtype=float32, place=Place(gpu:0), stop_gradient=False,
       [[0.14612700]]), Tensor(shape=[1, 1], dtype=float32, place=Place(gpu:0), stop_gradient=False,
       [[0.40763599]]), Tensor(shape=[1, 1], dtype=float32, place=Place(gpu:0), stop_gradient=False,
       [[1.54426730]]), Tensor(shape=[1, 1], dtype=float32, place=Place(gpu:0), stop_gradient=False,
       [[0.12621829]]), Tensor(shape=[1, 1], dtype=float32, place=Place(gpu:0), stop_gradient=False,
       [[0.97957349]]), Tensor(shape=[1, 1], dtype=float32, place=Place(gpu:0), stop_gradient=False,
       [[-0.00884005]]), Tensor(shape=[1, 1], dtype=float32, place=Place(gpu:0), stop_gradient=False,
       [[-0.28282693]]), Tensor(shape=[1, 1], dtype=float32, place=Place(gpu:0), stop_gradient=False,
       [[-0.44169435]]), Tensor(shape=[1, 1], dtype=float32, place=Place(gpu:0), stop_gradient=False,
       [[0.40584773]]), Tensor(shape=[1, 1], dtype=float32, place=Place(gpu:0), stop_gradient=False,
       [[0.16409793]]), Tensor(shape=[1, 1], dtype=float32, place=Place(gpu:0), stop_gradient=False,
       [[0.55420506]]), Tensor(shape=[1, 1], dtype=float32, place=Place(gpu:0), stop_gradient=False,
       [[0.30608740]]), Tensor(shape=[1, 1], dtype=float32, place=Place(gpu:0), stop_gradient=False,
       [[0.49449006]]), Tensor(shape=[1, 1], dtype=float32, place=Place(gpu:0), stop_gradient=False,
       [[0.02781016]]), Tensor(shape=[1, 1], dtype=float32, place=Place(gpu:0), stop_gradient=False,
       [[0.04644860]]), Tensor(shape=[1, 1], dtype=float32, place=Place(gpu:0), stop_gradient=False,
       [[0.79522288]]), Tensor(shape=[1, 1], dtype=float32, place=Place(gpu:0), stop_gradient=False,
       [[0.11904773]]), Tensor(shape=[1, 1], dtype=float32, place=Place(gpu:0), stop_gradient=False,
       [[-0.47921237]]), Tensor(shape=[1, 1], dtype=float32, place=Place(gpu:0), stop_gradient=False,
       [[-0.21942130]]), Tensor(shape=[1, 1], dtype=float32, place=Place(gpu:0), stop_gradient=False,
       [[-0.25088710]]), Tensor(shape=[1, 1], dtype=float32, place=Place(gpu:0), stop_gradient=False,
       [[0.31529802]]), Tensor(shape=[1, 1], dtype=float32, place=Place(gpu:0), stop_gradient=False,
       [[0.11372295]]), Tensor(shape=[1, 1], dtype=float32, place=Place(gpu:0), stop_gradient=False,
       [[0.15712427]]), Tensor(shape=[1, 1], dtype=float32, place=Place(gpu:0), stop_gradient=False,
       [[0.58457565]]), Tensor(shape=[1, 1], dtype=float32, place=Place(gpu:0), stop_gradient=False,
       [[0.40284061]]), Tensor(shape=[1, 1], dtype=float32, place=Place(gpu:0), stop_gradient=False,
       [[0.34274596]]), Tensor(shape=[1, 1], dtype=float32, place=Place(gpu:0), stop_gradient=False,
       [[0.78810346]]), Tensor(shape=[1, 1], dtype=float32, place=Place(gpu:0), stop_gradient=False,
       [[-0.22440287]]), Tensor(shape=[1, 1], dtype=float32, place=Place(gpu:0), stop_gradient=False,
       [[0.52228999]]), Tensor(shape=[1, 1], dtype=float32, place=Place(gpu:0), stop_gradient=False,
       [[0.38588661]]), Tensor(shape=[1, 1], dtype=float32, place=Place(gpu:0), stop_gradient=False,
       [[0.15205957]]), Tensor(shape=[1, 1], dtype=float32, place=Place(gpu:0), stop_gradient=False,
       [[0.09741980]]), Tensor(shape=[1, 1], dtype=float32, place=Place(gpu:0), stop_gradient=False,
       [[0.13445786]]), Tensor(shape=[1, 1], dtype=float32, place=Place(gpu:0), stop_gradient=False,
       [[0.20310366]]), Tensor(shape=[1, 1], dtype=float32, place=Place(gpu:0), stop_gradient=False,
       [[0.05031108]]), Tensor(shape=[1, 1], dtype=float32, place=Place(gpu:0), stop_gradient=False,
       [[-0.46788487]]), Tensor(shape=[1, 1], dtype=float32, place=Place(gpu:0), stop_gradient=False,
       [[0.24416491]]), Tensor(shape=[1, 1], dtype=float32, place=Place(gpu:0), stop_gradient=False,
       [[-0.52382004]]), Tensor(shape=[1, 1], dtype=float32, place=Place(gpu:0), stop_gradient=False,
       [[-0.06532061]]), Tensor(shape=[1, 1], dtype=float32, place=Place(gpu:0), stop_gradient=False,
       [[-0.53144491]]), Tensor(shape=[1, 1], dtype=float32, place=Place(gpu:0), stop_gradient=False,
       [[0.33535960]]), Tensor(shape=[1, 1], dtype=float32, place=Place(gpu:0), stop_gradient=False,
       [[0.73592830]]), Tensor(shape=[1, 1], dtype=float32, place=Place(gpu:0), stop_gradient=False,
       [[-0.33153993]]), Tensor(shape=[1, 1], dtype=float32, place=Place(gpu:0), stop_gradient=False,
       [[-0.06309694]]), Tensor(shape=[1, 1], dtype=float32, place=Place(gpu:0), stop_gradient=False,
       [[-0.20155904]]), Tensor(shape=[1, 1], dtype=float32, place=Place(gpu:0), stop_gradient=False,
       [[0.44570580]]), Tensor(shape=[1, 1], dtype=float32, place=Place(gpu:0), stop_gradient=False,
       [[0.08384399]]), Tensor(shape=[1, 1], dtype=float32, place=Place(gpu:0), stop_gradient=False,
       [[0.35838705]]), Tensor(shape=[1, 1], dtype=float32, place=Place(gpu:0), stop_gradient=False,
       [[0.46934620]]), Tensor(shape=[1, 1], dtype=float32, place=Place(gpu:0), stop_gradient=False,
       [[0.49268493]]), Tensor(shape=[1, 1], dtype=float32, place=Place(gpu:0), stop_gradient=False,
       [[-0.04641798]]), Tensor(shape=[1, 1], dtype=float32, place=Place(gpu:0), stop_gradient=False,
       [[0.15203755]]), Tensor(shape=[1, 1], dtype=float32, place=Place(gpu:0), stop_gradient=False,
       [[0.42403418]]), Tensor(shape=[1, 1], dtype=float32, place=Place(gpu:0), stop_gradient=False,
       [[0.60045838]]), Tensor(shape=[1, 1], dtype=float32, place=Place(gpu:0), stop_gradient=False,
       [[0.24354461]]), Tensor(shape=[1, 1], dtype=float32, place=Place(gpu:0), stop_gradient=False,
       [[0.07905102]]), Tensor(shape=[1, 1], dtype=float32, place=Place(gpu:0), stop_gradient=False,
       [[0.54188943]]), Tensor(shape=[1, 1], dtype=float32, place=Place(gpu:0), stop_gradient=False,
       [[-0.09376356]]), Tensor(shape=[1, 1], dtype=float32, place=Place(gpu:0), stop_gradient=False,
       [[0.07086556]]), Tensor(shape=[1, 1], dtype=float32, place=Place(gpu:0), stop_gradient=False,
       [[0.12033543]]), Tensor(shape=[1, 1], dtype=float32, place=Place(gpu:0), stop_gradient=False,
       [[0.00973678]]), Tensor(shape=[1, 1], dtype=float32, place=Place(gpu:0), stop_gradient=False,
       [[-0.26597875]]), Tensor(shape=[1, 1], dtype=float32, place=Place(gpu:0), stop_gradient=False,
       [[0.10573357]]), Tensor(shape=[1, 1], dtype=float32, place=Place(gpu:0), stop_gradient=False,
       [[0.52661669]]), Tensor(shape=[1, 1], dtype=float32, place=Place(gpu:0), stop_gradient=False,
       [[0.11851332]]), Tensor(shape=[1, 1], dtype=float32, place=Place(gpu:0), stop_gradient=False,
       [[0.85310972]]), Tensor(shape=[1, 1], dtype=float32, place=Place(gpu:0), stop_gradient=False,
       [[-0.96144092]]), Tensor(shape=[1, 1], dtype=float32, place=Place(gpu:0), stop_gradient=False,
       [[0.80334806]]), Tensor(shape=[1, 1], dtype=float32, place=Place(gpu:0), stop_gradient=False,
       [[0.11293778]]), Tensor(shape=[1, 1], dtype=float32, place=Place(gpu:0), stop_gradient=False,
       [[0.12638660]]), Tensor(shape=[1, 1], dtype=float32, place=Place(gpu:0), stop_gradient=False,
       [[0.65866530]]), Tensor(shape=[1, 1], dtype=float32, place=Place(gpu:0), stop_gradient=False,
       [[-0.88422561]]), Tensor(shape=[1, 1], dtype=float32, place=Place(gpu:0), stop_gradient=False,
       [[-0.14159554]]), Tensor(shape=[1, 1], dtype=float32, place=Place(gpu:0), stop_gradient=False,
       [[0.32514289]]), Tensor(shape=[1, 1], dtype=float32, place=Place(gpu:0), stop_gradient=False,
       [[-0.28985247]]), Tensor(shape=[1, 1], dtype=float32, place=Place(gpu:0), stop_gradient=False,
       [[-0.21863467]]), Tensor(shape=[1, 1], dtype=float32, place=Place(gpu:0), stop_gradient=False,
       [[-0.16769901]]), Tensor(shape=[1, 1], dtype=float32, place=Place(gpu:0), stop_gradient=False,
       [[0.28093368]]), Tensor(shape=[1, 1], dtype=float32, place=Place(gpu:0), stop_gradient=False,
       [[0.24580508]]), Tensor(shape=[1, 1], dtype=float32, place=Place(gpu:0), stop_gradient=False,
       [[1.33940685]]), Tensor(shape=[1, 1], dtype=float32, place=Place(gpu:0), stop_gradient=False,
       [[-0.07320566]]), Tensor(shape=[1, 1], dtype=float32, place=Place(gpu:0), stop_gradient=False,
       [[0.19715047]]), Tensor(shape=[1, 1], dtype=float32, place=Place(gpu:0), stop_gradient=False,
       [[0.44033682]]), Tensor(shape=[1, 1], dtype=float32, place=Place(gpu:0), stop_gradient=False,
       [[0.13477851]]), Tensor(shape=[1, 1], dtype=float32, place=Place(gpu:0), stop_gradient=False,
       [[0.37601706]]), Tensor(shape=[1, 1], dtype=float32, place=Place(gpu:0), stop_gradient=False,
       [[0.61441523]]), Tensor(shape=[1, 1], dtype=float32, place=Place(gpu:0), stop_gradient=False,
       [[0.38144094]]), Tensor(shape=[1, 1], dtype=float32, place=Place(gpu:0), stop_gradient=False,
       [[0.55627668]]), Tensor(shape=[1, 1], dtype=float32, place=Place(gpu:0), stop_gradient=False,
       [[0.00794823]]), Tensor(shape=[1, 1], dtype=float32, place=Place(gpu:0), stop_gradient=False,
       [[-0.14110795]]), Tensor(shape=[1, 1], dtype=float32, place=Place(gpu:0), stop_gradient=False,
       [[0.04848848]]), Tensor(shape=[1, 1], dtype=float32, place=Place(gpu:0), stop_gradient=False,
       [[0.36352396]]), Tensor(shape=[1, 1], dtype=float32, place=Place(gpu:0), stop_gradient=False,
       [[0.27837858]]), Tensor(shape=[1, 1], dtype=float32, place=Place(gpu:0), stop_gradient=False,
       [[-0.07947430]]), Tensor(shape=[1, 1], dtype=float32, place=Place(gpu:0), stop_gradient=False,
       [[0.10192870]]), Tensor(shape=[1, 1], dtype=float32, place=Place(gpu:0), stop_gradient=False,
       [[0.24401200]]), Tensor(shape=[1, 1], dtype=float32, place=Place(gpu:0), stop_gradient=False,
       [[0.83408523]]), Tensor(shape=[1, 1], dtype=float32, place=Place(gpu:0), stop_gradient=False,
       [[0.44856891]]), Tensor(shape=[1, 1], dtype=float32, place=Place(gpu:0), stop_gradient=False,
       [[0.06447601]]), Tensor(shape=[1, 1], dtype=float32, place=Place(gpu:0), stop_gradient=False,
       [[0.17212763]]), Tensor(shape=[1, 1], dtype=float32, place=Place(gpu:0), stop_gradient=False,
       [[-0.18707243]]), Tensor(shape=[1, 1], dtype=float32, place=Place(gpu:0), stop_gradient=False,
       [[-0.11827999]]), Tensor(shape=[1, 1], dtype=float32, place=Place(gpu:0), stop_gradient=False,
       [[-0.37973288]]), Tensor(shape=[1, 1], dtype=float32, place=Place(gpu:0), stop_gradient=False,
       [[0.56238842]]), Tensor(shape=[1, 1], dtype=float32, place=Place(gpu:0), stop_gradient=False,
       [[-0.46713963]]), Tensor(shape=[1, 1], dtype=float32, place=Place(gpu:0), stop_gradient=False,
       [[0.47919673]]), Tensor(shape=[1, 1], dtype=float32, place=Place(gpu:0), stop_gradient=False,
       [[0.07199048]]), Tensor(shape=[1, 1], dtype=float32, place=Place(gpu:0), stop_gradient=False,
       [[-0.47425637]]), Tensor(shape=[1, 1], dtype=float32, place=Place(gpu:0), stop_gradient=False,
       [[0.12414902]]), Tensor(shape=[1, 1], dtype=float32, place=Place(gpu:0), stop_gradient=False,
       [[-0.13834774]]), Tensor(shape=[1, 1], dtype=float32, place=Place(gpu:0), stop_gradient=False,
       [[-0.31951672]]), Tensor(shape=[1, 1], dtype=float32, place=Place(gpu:0), stop_gradient=False,
       [[0.27122203]]), Tensor(shape=[1, 1], dtype=float32, place=Place(gpu:0), stop_gradient=False,
       [[-0.06265430]]), Tensor(shape=[1, 1], dtype=float32, place=Place(gpu:0), stop_gradient=False,
       [[-0.51172924]]), Tensor(shape=[1, 1], dtype=float32, place=Place(gpu:0), stop_gradient=False,
       [[0.50536525]]), Tensor(shape=[1, 1], dtype=float32, place=Place(gpu:0), stop_gradient=False,
       [[0.51465583]]), Tensor(shape=[1, 1], dtype=float32, place=Place(gpu:0), stop_gradient=False,
       [[-0.44701704]]), Tensor(shape=[1, 1], dtype=float32, place=Place(gpu:0), stop_gradient=False,
       [[0.39858559]]), Tensor(shape=[1, 1], dtype=float32, place=Place(gpu:0), stop_gradient=False,
       [[0.31886303]]), Tensor(shape=[1, 1], dtype=float32, place=Place(gpu:0), stop_gradient=False,
       [[0.29493463]]), Tensor(shape=[1, 1], dtype=float32, place=Place(gpu:0), stop_gradient=False,
       [[0.00735997]]), Tensor(shape=[1, 1], dtype=float32, place=Place(gpu:0), stop_gradient=False,
       [[-0.42210022]]), Tensor(shape=[1, 1], dtype=float32, place=Place(gpu:0), stop_gradient=False,
       [[-0.06257382]]), Tensor(shape=[1, 1], dtype=float32, place=Place(gpu:0), stop_gradient=False,
       [[0.76618671]]), Tensor(shape=[1, 1], dtype=float32, place=Place(gpu:0), stop_gradient=False,
       [[-0.59000134]]), Tensor(shape=[1, 1], dtype=float32, place=Place(gpu:0), stop_gradient=False,
       [[0.81734991]]), Tensor(shape=[1, 1], dtype=float32, place=Place(gpu:0), stop_gradient=False,
       [[-0.48811778]]), Tensor(shape=[1, 1], dtype=float32, place=Place(gpu:0), stop_gradient=False,
       [[0.50484604]]), Tensor(shape=[1, 1], dtype=float32, place=Place(gpu:0), stop_gradient=False,
       [[0.17658579]]), Tensor(shape=[1, 1], dtype=float32, place=Place(gpu:0), stop_gradient=False,
       [[0.15134256]]), Tensor(shape=[1, 1], dtype=float32, place=Place(gpu:0), stop_gradient=False,
       [[0.22699168]]), Tensor(shape=[1, 1], dtype=float32, place=Place(gpu:0), stop_gradient=False,
       [[-0.11169553]]), Tensor(shape=[1, 1], dtype=float32, place=Place(gpu:0), stop_gradient=False,
       [[-0.96924913]]), Tensor(shape=[1, 1], dtype=float32, place=Place(gpu:0), stop_gradient=False,
       [[0.01308975]]), Tensor(shape=[1, 1], dtype=float32, place=Place(gpu:0), stop_gradient=False,
       [[0.80368865]]), Tensor(shape=[1, 1], dtype=float32, place=Place(gpu:0), stop_gradient=False,
       [[-0.40497336]]), Tensor(shape=[1, 1], dtype=float32, place=Place(gpu:0), stop_gradient=False,
       [[-0.16192749]]), Tensor(shape=[1, 1], dtype=float32, place=Place(gpu:0), stop_gradient=False,
       [[-0.14131603]]), Tensor(shape=[1, 1], dtype=float32, place=Place(gpu:0), stop_gradient=False,
       [[1.22107267]]), Tensor(shape=[1, 1], dtype=float32, place=Place(gpu:0), stop_gradient=False,
       [[0.39507094]]), Tensor(shape=[1, 1], dtype=float32, place=Place(gpu:0), stop_gradient=False,
       [[-0.03073066]]), Tensor(shape=[1, 1], dtype=float32, place=Place(gpu:0), stop_gradient=False,
       [[0.27309778]]), Tensor(shape=[1, 1], dtype=float32, place=Place(gpu:0), stop_gradient=False,
       [[-0.00708114]]), Tensor(shape=[1, 1], dtype=float32, place=Place(gpu:0), stop_gradient=False,
       [[0.57821071]]), Tensor(shape=[1, 1], dtype=float32, place=Place(gpu:0), stop_gradient=False,
       [[0.33658504]]), Tensor(shape=[1, 1], dtype=float32, place=Place(gpu:0), stop_gradient=False,
       [[0.11668704]]), Tensor(shape=[1, 1], dtype=float32, place=Place(gpu:0), stop_gradient=False,
       [[0.66753232]]), Tensor(shape=[1, 1], dtype=float32, place=Place(gpu:0), stop_gradient=False,
       [[0.97967565]]), Tensor(shape=[1, 1], dtype=float32, place=Place(gpu:0), stop_gradient=False,
       [[-0.16306505]]), Tensor(shape=[1, 1], dtype=float32, place=Place(gpu:0), stop_gradient=False,
       [[0.05496188]]), Tensor(shape=[1, 1], dtype=float32, place=Place(gpu:0), stop_gradient=False,
       [[0.51948881]]), Tensor(shape=[1, 1], dtype=float32, place=Place(gpu:0), stop_gradient=False,
       [[0.67708051]]), Tensor(shape=[1, 1], dtype=float32, place=Place(gpu:0), stop_gradient=False,
       [[-0.05163373]]), Tensor(shape=[1, 1], dtype=float32, place=Place(gpu:0), stop_gradient=False,
       [[0.00239483]]), Tensor(shape=[1, 1], dtype=float32, place=Place(gpu:0), stop_gradient=False,
       [[0.14013566]]), Tensor(shape=[1, 1], dtype=float32, place=Place(gpu:0), stop_gradient=False,
       [[0.34191847]]), Tensor(shape=[1, 1], dtype=float32, place=Place(gpu:0), stop_gradient=False,
       [[0.25270984]]), Tensor(shape=[1, 1], dtype=float32, place=Place(gpu:0), stop_gradient=False,
       [[0.11080459]]), Tensor(shape=[1, 1], dtype=float32, place=Place(gpu:0), stop_gradient=False,
       [[0.48523274]]), Tensor(shape=[1, 1], dtype=float32, place=Place(gpu:0), stop_gradient=False,
       [[-0.19357768]]), Tensor(shape=[1, 1], dtype=float32, place=Place(gpu:0), stop_gradient=False,
       [[-0.17594978]]), Tensor(shape=[1, 1], dtype=float32, place=Place(gpu:0), stop_gradient=False,
       [[0.07142785]]), Tensor(shape=[1, 1], dtype=float32, place=Place(gpu:0), stop_gradient=False,
       [[0.20822111]]), Tensor(shape=[1, 1], dtype=float32, place=Place(gpu:0), stop_gradient=False,
       [[-0.08473505]]), Tensor(shape=[1, 1], dtype=float32, place=Place(gpu:0), stop_gradient=False,
       [[0.15897757]]), Tensor(shape=[1, 1], dtype=float32, place=Place(gpu:0), stop_gradient=False,
       [[0.13883314]]), Tensor(shape=[1, 1], dtype=float32, place=Place(gpu:0), stop_gradient=False,
       [[0.34538117]]), Tensor(shape=[1, 1], dtype=float32, place=Place(gpu:0), stop_gradient=False,
       [[-0.07930353]]), Tensor(shape=[1, 1], dtype=float32, place=Place(gpu:0), stop_gradient=False,
       [[-0.35454777]]), Tensor(shape=[1, 1], dtype=float32, place=Place(gpu:0), stop_gradient=False,
       [[0.58794606]]), Tensor(shape=[1, 1], dtype=float32, place=Place(gpu:0), stop_gradient=False,
       [[-0.33299047]]), Tensor(shape=[1, 1], dtype=float32, place=Place(gpu:0), stop_gradient=False,
       [[-0.25655201]]), Tensor(shape=[1, 1], dtype=float32, place=Place(gpu:0), stop_gradient=False,
       [[-0.10445303]]), Tensor(shape=[1, 1], dtype=float32, place=Place(gpu:0), stop_gradient=False,
       [[-0.04779747]]), Tensor(shape=[1, 1], dtype=float32, place=Place(gpu:0), stop_gradient=False,
       [[-0.10455710]]), Tensor(shape=[1, 1], dtype=float32, place=Place(gpu:0), stop_gradient=False,
       [[0.16646618]]), Tensor(shape=[1, 1], dtype=float32, place=Place(gpu:0), stop_gradient=False,
       [[0.31524831]]), Tensor(shape=[1, 1], dtype=float32, place=Place(gpu:0), stop_gradient=False,
       [[-0.04964443]]), Tensor(shape=[1, 1], dtype=float32, place=Place(gpu:0), stop_gradient=False,
       [[0.58060354]]), Tensor(shape=[1, 1], dtype=float32, place=Place(gpu:0), stop_gradient=False,
       [[0.02770084]]), Tensor(shape=[1, 1], dtype=float32, place=Place(gpu:0), stop_gradient=False,
       [[0.83897114]]), Tensor(shape=[1, 1], dtype=float32, place=Place(gpu:0), stop_gradient=False,
       [[-0.02168062]]), Tensor(shape=[1, 1], dtype=float32, place=Place(gpu:0), stop_gradient=False,
       [[-0.35580465]]), Tensor(shape=[1, 1], dtype=float32, place=Place(gpu:0), stop_gradient=False,
       [[-0.39009991]]), Tensor(shape=[1, 1], dtype=float32, place=Place(gpu:0), stop_gradient=False,
       [[-0.13909817]]), Tensor(shape=[1, 1], dtype=float32, place=Place(gpu:0), stop_gradient=False,
       [[-0.08075938]]), Tensor(shape=[1, 1], dtype=float32, place=Place(gpu:0), stop_gradient=False,
       [[-0.18590415]]), Tensor(shape=[1, 1], dtype=float32, place=Place(gpu:0), stop_gradient=False,
       [[-0.56150711]]), Tensor(shape=[1, 1], dtype=float32, place=Place(gpu:0), stop_gradient=False,
       [[0.18525685]]), Tensor(shape=[1, 1], dtype=float32, place=Place(gpu:0), stop_gradient=False,
       [[-0.01324606]]), Tensor(shape=[1, 1], dtype=float32, place=Place(gpu:0), stop_gradient=False,
       [[0.07201144]]), Tensor(shape=[1, 1], dtype=float32, place=Place(gpu:0), stop_gradient=False,
       [[0.28585029]]), Tensor(shape=[1, 1], dtype=float32, place=Place(gpu:0), stop_gradient=False,
       [[0.90698087]]), Tensor(shape=[1, 1], dtype=float32, place=Place(gpu:0), stop_gradient=False,
       [[0.20296726]]), Tensor(shape=[1, 1], dtype=float32, place=Place(gpu:0), stop_gradient=False,
       [[0.39485294]]), Tensor(shape=[1, 1], dtype=float32, place=Place(gpu:0), stop_gradient=False,
       [[-0.48382780]]), Tensor(shape=[1, 1], dtype=float32, place=Place(gpu:0), stop_gradient=False,
       [[-0.18443805]]), Tensor(shape=[1, 1], dtype=float32, place=Place(gpu:0), stop_gradient=False,
       [[0.38270891]]), Tensor(shape=[1, 1], dtype=float32, place=Place(gpu:0), stop_gradient=False,
       [[0.79779136]]), Tensor(shape=[1, 1], dtype=float32, place=Place(gpu:0), stop_gradient=False,
       [[-0.19123754]]), Tensor(shape=[1, 1], dtype=float32, place=Place(gpu:0), stop_gradient=False,
       [[1.21670949]]), Tensor(shape=[1, 1], dtype=float32, place=Place(gpu:0), stop_gradient=False,
       [[-0.01447338]]), Tensor(shape=[1, 1], dtype=float32, place=Place(gpu:0), stop_gradient=False,
       [[0.12670536]]), Tensor(shape=[1, 1], dtype=float32, place=Place(gpu:0), stop_gradient=False,
       [[0.01824123]]), Tensor(shape=[1, 1], dtype=float32, place=Place(gpu:0), stop_gradient=False,
       [[-0.14000210]]), Tensor(shape=[1, 1], dtype=float32, place=Place(gpu:0), stop_gradient=False,
       [[0.16719995]]), Tensor(shape=[1, 1], dtype=float32, place=Place(gpu:0), stop_gradient=False,
       [[-0.18032512]]), Tensor(shape=[1, 1], dtype=float32, place=Place(gpu:0), stop_gradient=False,
       [[0.18801895]]), Tensor(shape=[1, 1], dtype=float32, place=Place(gpu:0), stop_gradient=False,
       [[0.20721790]]), Tensor(shape=[1, 1], dtype=float32, place=Place(gpu:0), stop_gradient=False,
       [[0.75916696]]), Tensor(shape=[1, 1], dtype=float32, place=Place(gpu:0), stop_gradient=False,
       [[0.21391419]]), Tensor(shape=[1, 1], dtype=float32, place=Place(gpu:0), stop_gradient=False,
       [[-0.22957066]]), Tensor(shape=[1, 1], dtype=float32, place=Place(gpu:0), stop_gradient=False,
       [[0.35765213]]), Tensor(shape=[1, 1], dtype=float32, place=Place(gpu:0), stop_gradient=False,
       [[0.57816088]]), Tensor(shape=[1, 1], dtype=float32, place=Place(gpu:0), stop_gradient=False,
       [[0.53739858]]), Tensor(shape=[1, 1], dtype=float32, place=Place(gpu:0), stop_gradient=False,
       [[-0.08023025]]), Tensor(shape=[1, 1], dtype=float32, place=Place(gpu:0), stop_gradient=False,
       [[0.23322487]]), Tensor(shape=[1, 1], dtype=float32, place=Place(gpu:0), stop_gradient=False,
       [[0.27490732]]), Tensor(shape=[1, 1], dtype=float32, place=Place(gpu:0), stop_gradient=False,
       [[0.11255787]]), Tensor(shape=[1, 1], dtype=float32, place=Place(gpu:0), stop_gradient=False,
       [[0.90063202]]), Tensor(shape=[1, 1], dtype=float32, place=Place(gpu:0), stop_gradient=False,
       [[-0.21748936]]), Tensor(shape=[1, 1], dtype=float32, place=Place(gpu:0), stop_gradient=False,
       [[0.46920335]]), Tensor(shape=[1, 1], dtype=float32, place=Place(gpu:0), stop_gradient=False,
       [[-1.03563023]]), Tensor(shape=[1, 1], dtype=float32, place=Place(gpu:0), stop_gradient=False,
       [[0.07641967]]), Tensor(shape=[1, 1], dtype=float32, place=Place(gpu:0), stop_gradient=False,
       [[0.28591272]]), Tensor(shape=[1, 1], dtype=float32, place=Place(gpu:0), stop_gradient=False,
       [[0.60917199]]), Tensor(shape=[1, 1], dtype=float32, place=Place(gpu:0), stop_gradient=False,
       [[0.27543157]]), Tensor(shape=[1, 1], dtype=float32, place=Place(gpu:0), stop_gradient=False,
       [[0.30377823]]), Tensor(shape=[1, 1], dtype=float32, place=Place(gpu:0), stop_gradient=False,
       [[0.01602978]]), Tensor(shape=[1, 1], dtype=float32, place=Place(gpu:0), stop_gradient=False,
       [[0.36365208]]), Tensor(shape=[1, 1], dtype=float32, place=Place(gpu:0), stop_gradient=False,
       [[0.63090140]]), Tensor(shape=[1, 1], dtype=float32, place=Place(gpu:0), stop_gradient=False,
       [[-0.06347218]]), Tensor(shape=[1, 1], dtype=float32, place=Place(gpu:0), stop_gradient=False,
       [[0.05933932]]), Tensor(shape=[1, 1], dtype=float32, place=Place(gpu:0), stop_gradient=False,
       [[0.70915890]]), Tensor(shape=[1, 1], dtype=float32, place=Place(gpu:0), stop_gradient=False,
       [[0.72446680]]), Tensor(shape=[1, 1], dtype=float32, place=Place(gpu:0), stop_gradient=False,
       [[0.96640921]]), Tensor(shape=[1, 1], dtype=float32, place=Place(gpu:0), stop_gradient=False,
       [[0.29156765]]), Tensor(shape=[1, 1], dtype=float32, place=Place(gpu:0), stop_gradient=False,
       [[0.35821834]]), Tensor(shape=[1, 1], dtype=float32, place=Place(gpu:0), stop_gradient=False,
       [[-0.42687842]]), Tensor(shape=[1, 1], dtype=float32, place=Place(gpu:0), stop_gradient=False,
       [[-0.43299255]]), Tensor(shape=[1, 1], dtype=float32, place=Place(gpu:0), stop_gradient=False,
       [[0.41873679]]), Tensor(shape=[1, 1], dtype=float32, place=Place(gpu:0), stop_gradient=False,
       [[-0.24981216]]), Tensor(shape=[1, 1], dtype=float32, place=Place(gpu:0), stop_gradient=False,
       [[0.69104838]]), Tensor(shape=[1, 1], dtype=float32, place=Place(gpu:0), stop_gradient=False,
       [[-0.04902317]]), Tensor(shape=[1, 1], dtype=float32, place=Place(gpu:0), stop_gradient=False,
       [[0.06218195]]), Tensor(shape=[1, 1], dtype=float32, place=Place(gpu:0), stop_gradient=False,
       [[0.31550786]]), Tensor(shape=[1, 1], dtype=float32, place=Place(gpu:0), stop_gradient=False,
       [[-0.45310614]]), Tensor(shape=[1, 1], dtype=float32, place=Place(gpu:0), stop_gradient=False,
       [[0.17188393]]), Tensor(shape=[1, 1], dtype=float32, place=Place(gpu:0), stop_gradient=False,
       [[-0.12393215]]), Tensor(shape=[1, 1], dtype=float32, place=Place(gpu:0), stop_gradient=False,
       [[0.57967651]]), Tensor(shape=[1, 1], dtype=float32, place=Place(gpu:0), stop_gradient=False,
       [[0.20886803]]), Tensor(shape=[1, 1], dtype=float32, place=Place(gpu:0), stop_gradient=False,
       [[0.14294177]]), Tensor(shape=[1, 1], dtype=float32, place=Place(gpu:0), stop_gradient=False,
       [[-0.49980709]]), Tensor(shape=[1, 1], dtype=float32, place=Place(gpu:0), stop_gradient=False,
       [[-0.28482857]]), Tensor(shape=[1, 1], dtype=float32, place=Place(gpu:0), stop_gradient=False,
       [[0.00266491]]), Tensor(shape=[1, 1], dtype=float32, place=Place(gpu:0), stop_gradient=False,
       [[-0.56916320]]), Tensor(shape=[1, 1], dtype=float32, place=Place(gpu:0), stop_gradient=False,
       [[0.31185475]]), Tensor(shape=[1, 1], dtype=float32, place=Place(gpu:0), stop_gradient=False,
       [[-0.71436346]]), Tensor(shape=[1, 1], dtype=float32, place=Place(gpu:0), stop_gradient=False,
       [[0.66652203]]), Tensor(shape=[1, 1], dtype=float32, place=Place(gpu:0), stop_gradient=False,
       [[0.32023388]]), Tensor(shape=[1, 1], dtype=float32, place=Place(gpu:0), stop_gradient=False,
       [[-0.45304009]]), Tensor(shape=[1, 1], dtype=float32, place=Place(gpu:0), stop_gradient=False,
       [[0.32588464]]), Tensor(shape=[1, 1], dtype=float32, place=Place(gpu:0), stop_gradient=False,
       [[0.16148154]]), Tensor(shape=[1, 1], dtype=float32, place=Place(gpu:0), stop_gradient=False,
       [[0.42767087]]), Tensor(shape=[1, 1], dtype=float32, place=Place(gpu:0), stop_gradient=False,
       [[0.60954678]]), Tensor(shape=[1, 1], dtype=float32, place=Place(gpu:0), stop_gradient=False,
       [[0.85734975]]), Tensor(shape=[1, 1], dtype=float32, place=Place(gpu:0), stop_gradient=False,
       [[0.55337751]]), Tensor(shape=[1, 1], dtype=float32, place=Place(gpu:0), stop_gradient=False,
       [[0.25894463]]), Tensor(shape=[1, 1], dtype=float32, place=Place(gpu:0), stop_gradient=False,
       [[0.32260633]]), Tensor(shape=[1, 1], dtype=float32, place=Place(gpu:0), stop_gradient=False,
       [[0.03098416]]), Tensor(shape=[1, 1], dtype=float32, place=Place(gpu:0), stop_gradient=False,
       [[-0.13747558]]), Tensor(shape=[1, 1], dtype=float32, place=Place(gpu:0), stop_gradient=False,
       [[-0.09666431]]), Tensor(shape=[1, 1], dtype=float32, place=Place(gpu:0), stop_gradient=False,
       [[-0.45293269]]), Tensor(shape=[1, 1], dtype=float32, place=Place(gpu:0), stop_gradient=False,
       [[-0.19382098]]), Tensor(shape=[1, 1], dtype=float32, place=Place(gpu:0), stop_gradient=False,
       [[-0.40163389]]), Tensor(shape=[1, 1], dtype=float32, place=Place(gpu:0), stop_gradient=False,
       [[0.42662674]]), Tensor(shape=[1, 1], dtype=float32, place=Place(gpu:0), stop_gradient=False,
       [[0.05361977]]), Tensor(shape=[1, 1], dtype=float32, place=Place(gpu:0), stop_gradient=False,
       [[-0.38799116]]), Tensor(shape=[1, 1], dtype=float32, place=Place(gpu:0), stop_gradient=False,
       [[0.02736823]]), Tensor(shape=[1, 1], dtype=float32, place=Place(gpu:0), stop_gradient=False,
       [[-0.02932636]]), Tensor(shape=[1, 1], dtype=float32, place=Place(gpu:0), stop_gradient=False,
       [[0.10339427]]), Tensor(shape=[1, 1], dtype=float32, place=Place(gpu:0), stop_gradient=False,
       [[0.46115249]]), Tensor(shape=[1, 1], dtype=float32, place=Place(gpu:0), stop_gradient=False,
       [[0.36047184]]), Tensor(shape=[1, 1], dtype=float32, place=Place(gpu:0), stop_gradient=False,
       [[-0.33328989]]), Tensor(shape=[1, 1], dtype=float32, place=Place(gpu:0), stop_gradient=False,
       [[0.11792254]]), Tensor(shape=[1, 1], dtype=float32, place=Place(gpu:0), stop_gradient=False,
       [[-0.06596407]]), Tensor(shape=[1, 1], dtype=float32, place=Place(gpu:0), stop_gradient=False,
       [[0.10048011]]), Tensor(shape=[1, 1], dtype=float32, place=Place(gpu:0), stop_gradient=False,
       [[0.21324658]]), Tensor(shape=[1, 1], dtype=float32, place=Place(gpu:0), stop_gradient=False,
       [[-0.11020529]]), Tensor(shape=[1, 1], dtype=float32, place=Place(gpu:0), stop_gradient=False,
       [[0.08897623]]), Tensor(shape=[1, 1], dtype=float32, place=Place(gpu:0), stop_gradient=False,
       [[0.17561601]]), Tensor(shape=[1, 1], dtype=float32, place=Place(gpu:0), stop_gradient=False,
       [[0.11536156]]), Tensor(shape=[1, 1], dtype=float32, place=Place(gpu:0), stop_gradient=False,
       [[-0.93352878]]), Tensor(shape=[1, 1], dtype=float32, place=Place(gpu:0), stop_gradient=False,
       [[0.35112262]]), Tensor(shape=[1, 1], dtype=float32, place=Place(gpu:0), stop_gradient=False,
       [[0.22222342]]), Tensor(shape=[1, 1], dtype=float32, place=Place(gpu:0), stop_gradient=False,
       [[-0.04151958]]), Tensor(shape=[1, 1], dtype=float32, place=Place(gpu:0), stop_gradient=False,
       [[-0.39091966]]), Tensor(shape=[1, 1], dtype=float32, place=Place(gpu:0), stop_gradient=False,
       [[-0.44056484]]), Tensor(shape=[1, 1], dtype=float32, place=Place(gpu:0), stop_gradient=False,
       [[-0.50789940]]), Tensor(shape=[1, 1], dtype=float32, place=Place(gpu:0), stop_gradient=False,
       [[-1.01449597]]), Tensor(shape=[1, 1], dtype=float32, place=Place(gpu:0), stop_gradient=False,
       [[0.64409053]]), Tensor(shape=[1, 1], dtype=float32, place=Place(gpu:0), stop_gradient=False,
       [[0.03456168]]), Tensor(shape=[1, 1], dtype=float32, place=Place(gpu:0), stop_gradient=False,
       [[-0.40700445]]), Tensor(shape=[1, 1], dtype=float32, place=Place(gpu:0), stop_gradient=False,
       [[0.16290851]]), Tensor(shape=[1, 1], dtype=float32, place=Place(gpu:0), stop_gradient=False,
       [[-0.12790632]]), Tensor(shape=[1, 1], dtype=float32, place=Place(gpu:0), stop_gradient=False,
       [[0.41777393]])]
登录后复制

In [39]
predict_result = np.array(predict_result)
predict_result_new = predict_result.reshape(-1,1)

test_data_y_new = test_data_y
登录后复制


9. 可视化预测值与真实值

In [40]
# 绘制预测与真值结果plt.figure(figsize=(12,5), dpi=80)

plt.plot(test_data_y_new[:100], label="True value")
plt.plot(predict_result_new[:100], label="Pred value")

plt.xlabel("Sample",fontproperties = 'Times New Roman', size = 18)
plt.ylabel("Value",fontproperties = 'Times New Roman', size = 18)
plt.legend(loc='best')

plt.yticks(fontproperties = 'Times New Roman', size = 18)
plt.xticks(fontproperties = 'Times New Roman', size = 18)

plt.title("True VS Pred",fontproperties = 'Times New Roman', size = 18)
plt.legend(loc="best")
plt.show()
登录后复制

<Figure size 960x400 with 1 Axes>
登录后复制


10. 总结

  • 本项目搭建人工神经网络实现了蒸汽量回归预测。
  • 做了数据处理部分,包括异常值处理、相关性分析等。
  • 在今后,可以考虑使用其他网络模型进行预测,例如卷积网络。
  • 另外,可以尝试进一步优化超参数来优化模型。

以上就是工业蒸汽量预测的详细内容,更多请关注php中文网其它相关文章!

最佳 Windows 性能的顶级免费优化软件
最佳 Windows 性能的顶级免费优化软件

每个人都需要一台速度更快、更稳定的 PC。随着时间的推移,垃圾文件、旧注册表数据和不必要的后台进程会占用资源并降低性能。幸运的是,许多工具可以让 Windows 保持平稳运行。

下载
来源:php中文网
本文内容由网友自发贡献,版权归原作者所有,本站不承担相应法律责任。如您发现有涉嫌抄袭侵权的内容,请联系admin@php.cn
最新问题
开源免费商场系统广告
热门教程
更多>
最新下载
更多>
网站特效
网站源码
网站素材
前端模板
关于我们 免责申明 意见反馈 讲师合作 广告合作 最新更新 English
php中文网:公益在线php培训,帮助PHP学习者快速成长!
关注服务号 技术交流群
PHP中文网订阅号
每天精选资源文章推送
PHP中文网APP
随时随地碎片化学习

Copyright 2014-2025 https://www.php.cn/ All Rights Reserved | php.cn | 湘ICP备2023035733号
